Item No
1R0W
FHC Mobile Hydraulic Boom Glass Manipulator With Manual Crank Winch
Unit Of MeasureEA
Features, Advantages, and Benefits
- FOB Dallas, TX If No Stock In South Gate, CA
- 9-ft Max Lift Without Extension
- 7-ft Mast
- Automatic Brake Winch With 25-Ft Stainless Steel Cable and Hook
- 1000-Lb. Capacity Heavy Duty Hydraulic Boom Manipulator / Lifter
- OPTIONAL Bars Available To Stabilize Large Loads and Extension Boom Bar To Extend Reach On Those Inset Or Obstructed Glass Installs Requiring Additional Reach
- Also Available with Electric Winch, Call or Chat with us for Pricing and Availability.
Overview
The FHC Hydraulic Boom Manipulator is used in conjunction with the Vacuum Lifting Frames to manually lift and maneuver the loads or any other type of Manipulations that require a lifting device. The Reversible Boom allows you to point the legs in opposite direction to bring lifting point (hook end) closer to the source being lifted. The Boom Assembles/Disassembles in minutes to be transported and or to store away when not in use. To Counterbalance and Safely Manipulate the Boom with heavy loads use Plywood Sheets to create a flat platform over the legs and place either Center Blocks, Bricks, Cement Sacks, Sand Bags, Weights, Drums filled with Water or Sand that would be at least 20% more in weight than the item being lifted.*Do not exceed the max recommended capacity and always wear the appropriate safety gear to protect yourself and others. Failure to do so may cause serious injury to the operator and those around you.
Images shown are close representations of the product. Colors might vary depending on your computer's video display capabilities and or surrounding lights while viewing / during image shooting.
Please contact us at (888) 295-4531 or fhc@fhc-usa.com if there's any concern.| Product Name | FHC Mobile Hydraulic Boom Glass Manipulator With Manual Crank Winch |
|---|---|
| Item No | 1R0W |
| Compare To | R0W1 |
| Custom Length | N/A |
| Minimum Order Quantity | 1 |
| Product Height | MAST @ 80" W/CRANK / 9-FT MAX LIFT |
| Product Length | 74" |
| Product Warning | *Always wear the appropriate safety gear to protect yourself. Failure to do so may cause serious operator injury. *Images shown are close representations of the product. Colors might vary depending on your computer's video display capabilities. |
| Product Weight | 350 Lb. |
| Product Width | 41" |
| Ship Via | COMMON CARRIER TRUCK |
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
