Features, Advantages, & Benefits
Item NoGLENS2BNM
GLENS2BNM Glendale Series Wall Mount Hinge - Short Back Plate - Brushed Nickel
Unit Of Measure EA
*Actual product colors may vary from the images shown.
Features, Advantages, & Benefits
Item NoGLENS2BNM
FHC Glendale Series Wall Mount Hinge - Short Back Plate - Brushed Nickel
Unit Of Measure EA
Features, Advantages, & Benefits
Square Profile Glass to Wall Hinge with Short Back Plate
Designed For 3/8"-1/2" (10 mm to 12 mm) Tempered Glass
Many Popular Finishes to Select From
Self-Centering within 15 Degrees of Closing Position
Commonly used in Residential Bath and Commercial Hotel Applications
Reversible 5 Deg Pivot Pin For Jobs Requiring a Positive Closing Position
Features, Advantages, & Benefits
Glass Specifications
| MAXIMUM DOOR CAPACITY | 3/8" (10 mm) GLASS Approx. 5 lb/ft² |
1/2" (12 mm) GLASS Approx. 6.4 lb/ft² |
|---|---|---|
| DOOR WEIGHT | DOOR WIDTH | |
| Using 2 Hinges | 80 LBS (36 kg) | 28" (711 mm) |
| Using 3 Hinges | 120 LBS. (54 kg) | 32" (813 mm) |
NOTE: Do Not Exceed either maximum weight or width when choosing proper quantity of hinges.
| Product Name | FHC Glendale Series Wall Mount Hinge - Short Back Plate - Brushed Nickel |
|---|---|
| Item No | GLENS2BNM |
| Weight | 0.000000 |
| Select Your Color/Finish | Brushed Nickel |
| Compare To | GEN074BN HGTWBN C500010BRN |
| Minimum Order Quantity | 1 |
| Warranty | 15 - Year Warranty |
