SECTION 4 FHC ALUMINUM STOREFRONTS AND ENTRANCES
®
FHC Ladder Pulls
FHC "D" Shape Requires (2) 5/8"
Diameter Holes
Back-to-Back In Glass
Ladder Pulls
- For Glass, Aluminum, and Wood
Door Mounting Center To Overall
Length
Center
- Includes Mounting Hardware Mounting
for Various
Door Mounting Thicknesses
(Item No. B4LH)
- Easy to Install
- Custom Finishes and Lengths Available Finishes
Available Upon Request Includes Mounting
Hardware For Various 1-1/4" "D" Tubing
Mounting Thicknesses 304 Grade Stainless
Steel Construction
FHC Replacement Optional FHC Offset Post BS PS MB
Mounting Posts for for Ladder Handles STAINLESS STAINLESS MATTE
BRUSHED
POLISHED
BLACK
Ladder Handles - Optional Offset Mount Mid-Post FHC "D" SHAPE LADDER PULLS
Used With FHC Ladder Pulls CENTER-
- Typically Used If Overall Height - Two Back-to-Back Mounts Provided TO-CENTER
Exceeds 84" ITEM NO. OVERALL SIZE MOUNTING FINISH
With Each Kit
- Helps Ensure Proper Alignment of - M6-1 Threading 24DLHBS 24" Overall Length 12" Brushed Stainless
Mounting Points for Long Ladder 24DLHPS 24" Overall Length 12" Polished Stainless
Pull Handles - Available in Three 24DLHMB 24" Overall Length 12" Matte Black
Architectural 36DLHBS 36" Overall Length 24" Brushed Stainless
Finishes
36DLHMB 36" Overall Length 24" Matte Black
36DLHPS 36" Overall Length 24" Polished Stainless
48DLHBS 48" Overall Length 36" Brushed Stainless
48DLHPS 48" Overall Length 36" Polished Stainless
ITEM NO. LHMP1 ITEM NO. LH0P2 48DLHMB 48" Overall Length 36" Matte Black
Minimum Order 1 Set Minimum Order 1 Set Minimum order: 1 each.
FHC Square FHC SQUARE LADDER PULLS
Back-to-Back ITEM NO. OVERALL SIZE CENTER- FINISH
TO-CENTER
MOUNTING
Ladder Pulls 24SQLHBS 24" Overall Length 12" Brushed Stainless
24" Overall Length
24SQLHPS
12"
Polished Stainless
24SQLHMB
24" Overall Length
12"
Dark Bronze Anodized
24SQLHDU 24" Overall Length 12" Matte Black
- For Glass, Aluminum, and Wood Door 36SQLHBS 36" Overall Length 24" Brushed Stainless
Mounting 36SQLHMB 36" Overall Length 24" Matte Black
36SQLHPS 36" Overall Length 24" Polished Stainless
- Includes Mounting Hardware for 48SQLHBS 48" Overall Length 36" Brushed Stainless
Various Door Mounting Thicknesses 48SQLHPS 48" Overall Length 36" Polished Stainless
1-1/4" Square Tubing
(Item No. B4LH) 304 Grade Stainless Steel 48SQLHMB 48" Overall Length 36" Matte Black
Dark Bronze Anodized
36"
48" Overall Length
48SQLHDU
- Easy to Install Construction Minimum order: 1 each.
- Custom Finishes and Lengths Available Finishes
Available Upon Request
BS PS MB DU
BRUSHED POLISHED MATTE DARK BRONZE
STAINLESS STAINLESS BLACK ANODIZED
visit fhc-usa.com to search for
Ladder Pulls
Enter the Item Number or scan QR code with
144 your smartphone for complete product details
