SECTION 1 FRAMELESS SHOWER DOOR HINGES
SECTION 1

PROFESSIONAL GRADE

FHC Jamb

Mounted Hinge Kits

- For 3/8" to 1/2" Tempered Glass 1
- Available in Four Different
Hinge Models
- 78" Height
- Single Acting, Outswing Doors

Available Finishes

CH BN MB
POLISHED BRUSHED MATTE
CHROME NICKEL BLACK
Jamb Mounted Hinge Kits Include 2

- Aluminum Jamb,
with Two Matching
Finish Hinges
- Aluminum Strike
Jamb with Vinyl In
Matching Finish
- Bottom Door Wipe
With Drip Rail
- Mounting Hardware
Included
Aluminum Strike Jamb Included
(See Page 047 for Replacements)
GLENDALE & PRESTON MAXIMUM CAPACITY: 3

3/8" (10 mm) GLASS DIAL A GLASS
MAXIMUM DOOR Approx. 5 lb/ft 2
CAPACITY
DOOR WEIGHT DOOR WIDTH
USING 2 HINGES 80 LBS. (36 kg) 28" (711 mm)
NOTE: Do not exceed either maximum weight or width when choosing proper quantity of hinges.
4
VENICE & CAROLINA MAXIMUM CAPACITY:
3/8" (10 mm) GLASS
MAXIMUM DOOR Approx. 5 lb/ft 2
CAPACITY
DOOR WEIGHT DOOR WIDTH
USING 2 HINGES 100 LBS. (45 kg) 36" (914 mm) 1 Glendale Jamb 3 Aluminum Strike

NOTE: Do not exceed either maximum weight or width when choosing proper quantity of hinges. Mounted Hinge Jamb with Vinyl
VENICE & CAROLINA MAXIMUM CAPACITY: (See Page 047) Included With Kit
(See Page 047)
1/2" (12 mm) GLASS 2 Back-to-Back
MAXIMUM DOOR Approx. 6.4 lb/ft 2 Tubular Pull Handle 4 Bottom Wipes
CAPACITY
DOOR WEIGHT DOOR WIDTH (See Page 056) (See Page 108)
USING 2 HINGES 100 LBS. (45 kg) 30" (762 mm)
NOTE: Do not exceed either maximum weight or width when choosing proper quantity of hinges.
