SECTION 1
SECTION 1 FRAMELESS SHOWER DOOR HINGES
FHC Shower Hinge Replacement Parts

FHC 6 mm x 12 mm Hinge FHC 6 mm x 15 mm Hinge FHC 5 Degree
Cover Plate Screws Cover Plate Screws Pivot Pins
- 6 mm x 12 mm Long - 6 mm x 15 mm Long - Easy to Install
- Available in Seven Standard Finishes - Available in Seven Standard Finishes - Alters Door to
- For Glendale, Preston, Partriot, and - For Venice, Carolina, Patriot Grande, Press Snugly
Cambridge Hinges Cambria Grande, Pasadena, and Against Jamb
- 8 Per Pack Valore Hinges - Two Pivot Pins
- 8 Per Pack Per Set

Phillips Head Phillips Head
FHC's 5 Degree Pivot Pin sets are de-
Allen Head Allen Head signed to allow an additional 5 degrees
of closing for jobs that require a firmer
ALLEN HEAD PHILLIPS HEAD ALLEN HEAD PHILLIPS HEAD FINISH
ITEM NO. ITEM NO. FINISH ITEM NO. ITEM NO. positive position against a jamb or seal.
These Pivot Pins are installed prior
AL6X12CH PL6X12CH Polished Chrome AL6X15CH PL6X15CH Polished Chrome to installation of the hinge onto the
AL6X12BN PL6X12BN Brushed Nickel AL6X15BN PL6X15BN Brushed Nickel glass.
AL6X120RB PL6X120RB Oil Rubbed Bronze AL6X150RB PL6X150RB Oil Rubbed Bronze NOTE: P1VPN12 cannot be adapted
AL6X12MB PL6X12MB Matte Black AL6X15MB PL6X15MB Matte Black into header.
AL6X12PN PL6X12PN Polished Nickel AL6X15PN PL6X15PN Polished Nickel ITEM NO. DESCRIPTION GLASS SIZE
AL6X12SB PL6X12SB Satin Brass AL6X15SB PL6X15SB Satin Brass P1VPN38 Pivot Pin 3/8" (10 mm)
AL6X12BBRZ PL6X12BBRZ Brushed Bronze AL6X15BBRZ PL6X15BBRZ Brushed Bronze P1VPN12 Pivot Pin 1/2" (12 mm)
Minimum order: 1 pack. Minimum order: 1 pack. Minimum order: 1 set.
FHC #10 x 2" Wall Mount FHC #10 x 3" Wall Mount FHC #12 Wall Mount
Backplate Flat Head Backplate Flat Head Backplate Flat Head
Phillips Screws Phillips Screws Phillips Screws
- Heavy-Duty 304 Grade - Heavy-Duty 304 Grade - Two Sizes in #12 x 2" and #12 x 3"
- Stainless Steel Construction Stainless Steel Construction - Available in Seven Standard Finishes
- Use No.2 Point Phillips Bit (See Page 144) - Use No.2 Point Phillips Bit (See Page 144) - For Mounting Glass-to-Wall Hinges/
- For Mounting Glass-to-Wall Hinges and - For Mounting Glass-to-Wall Hinges and Grande Series Pivots
Our CSU4/CBU4 Clamps Our CSU4/CBU4 Clamps - 10 Per Pack
- 10 Screws Per Pack - 10 Screws Per Pack

2" Length 3" Length
#12 x 2" Screw #12 x 3" Screw

ITEM NO. FINISH ITEM NO. FINISH #12 X 2" #12 X 3" FINISH
ITEM NO. ITEM NO.
PS102CH Polished Chrome PS103CH Polished Chrome
PS122CH PS123CH Polished Chrome
PS102BN Brushed Nickel PS103BN Brushed Nickel
PS122BN PS123BN Brushed Nickel
PS1020RB Oil Rubbed Bronze PS1030RB Oil Rubbed Bronze
PS1220RB PS1230RB Oil Rubbed Bronze
PS102MB Matte Black PS103MB Matte Black
PS122MB PS123MB Matte Black
PS102PN Polished Nickel PS103PN Polished Nickel
PS122PN PS123PN Polished Nickel
PS102SB Satin Brass PS103SB Satin Brass
PS122SB PS123SB Satin Brass
PS102BBRZ Brushed Bronze PS103BBRZ Brushed Bronze
PS122BBRZ PS123BBRZ Brushed Bronze
Minimum order: 1 pack. Minimum order: 1 pack.
Minimum order: 1 pack.
XX = FINISH
visit fhc-usa.com to search for
THE GLAZING SUPPLY COMPANY Shower Parts
050 EXPERIENCE A ND INNO V A TION Enter the Item Number or scan QR code with
your smartphone for complete product details
