FHC PREMIUM ALUMINUM RAILING SYSTEMS SECTION 1
FHC X1 Arrowhead Series Premium Aluminum Railing

FHC X1 Series 2

Surface Mount Post Kits 1

- For 180 Degree,
90 Degree, and End Post
- 6005A-T61 Aluminum 3
- 2-3/8" Square Post
- Two Standard Post Heights
- Includes Post, Top Cap, Base
Plate, Washers and Buttons 7
- Available in Four Standard
Colors and Mill Aluminum
- Top Rail, Bottom Rail and
Glazing Vinyl Sold Separately
- Custom Heights and
Finishes Available
4

5

6
36" Post Kit

ITEM NO. SP136KXX WORKS WITH KIT COMPONENTS
2-3/8" x 2-3/8" Square AR 1 TC2XX Top Cap for 2-3/8" Square Post
Post Kit 37" Long ITEM NO.X1T20XX
Minimum Order: 1 Each. X1 Arrowhead Top 2 SP20XX 2-3/8 Square AR Post Extrusion
Rail (See Page 14)
3 SBP5XX 5" Square Base Plate
42" Post Kit ITEM NO.BRG20XX 4 BN1XX Plastic Snap-On Button
Bottom Rail With
ITEM NO. SP142KXX Glass Pocket 5 WSH1 Stainless Steel Washer
(See Page 14)
2-3/8" x 2-3/8" Square AR 6 BPS516 5/16" Base Plate Screw
Post Kit 43" Long
Minimum Order: 1 Each. 7 BPG5BL 5" Self Adhering Black Gasket

FHC Heavy-Duty
SURFACE MOUNT
Posts Only

- For 180 Degree, 90 Degree,
and End Post
.100 Wall
- 6005A-T61 Aluminum Thickness
- 2-3/8" Square Post 2-3/8"
- Available in Four Standard .25 Wall
Colors and Mill Aluminum Thickness

2-3/8"
Available Finishes

X1 SERIES SURFACE MOUNT POST ONLY
ITEM NO. DESCRIPTION POST HEIGHT/LENGTH
SP136XX 2-3/8 Square 36" AR Post 37"
SP142XX 2-3/8 Square 42" AR Post 43"
W BRZ MB S M
TRAFFIC DARK MATTE SILVER MILL ALUMINUM SP20XX 2-3/8 Square AR Post 241"
WHITE BRONZE BLACK METALLIC (Unpainted) Minimum order: 1 each.
XX Denotes Finish.
