SECTION 1 FHC PREMIUM ALUMINUM RAILING SYSTEMS
FHC X1 Arrowhead Series Premium Aluminum Railing

FHC X1 Slim Series

Slim Post Fascia Mount Post Kits

- For Center or End Posts 2
- 6005A-T61 Aluminum
- 2-3/8" X 1-1/8" Slim 1
AR Fascia Mount Post Kit
- Two Standard Post Heights 3
- Includes Post, Fascia
Bracket, Top Cap,
Washers and Buttons
- Available in Four Standard 7
Colors and Mill Aluminum 4
- Top Rail, Bottom Rail 8
and Glazing Vinyl
Sold Separately 5
- Custom Heights and
Finishes Available 6

36" Post Kit
WORKS WITH KIT COMPONENTS
ITEM NO. SL1F36KXX
2-3/8" x 1-1/8" Slim Fascia 1 TC1XX Top Cap for 1-1/8" x 2-3/8" Post
Post Kit 47" Long ITEM NO. X1T20XX 2 SL20XX 2-3/8" x 1-1/8" Slim Post
X1 Arrowhead Top Rail
Minimum Order: 1 Each. (See Page 14)
3 SPF1XX Fascia Mount Bracket
and Bottom Cover
42" Post Kit ITEM NO. BRG20XX 4 BN1XX Plastic Snap-On Button
Bottom Rail With
ITEM NO. SL1F42KXX Glass Pocket 5 WSH1 Stainless Steel Washer
(See Page 14)
2-3/8" x 1-1/8" Slim Fascia 6 BPS516 5/16" Base Plate Screw
Post Kit 53" Long
Minimum Order: 1 Each. 7 FBPS8 FHC #8 Flat Head Phillips Screws
8 BPG7BL 6" Long Black Gasket

FHC X1 Slim Series Fascia
.118" Wall
FASCIA MOUNT Thickness
Mount Slim Posts Only
- For Center and End Post
- 6005A-T61 Aluminum
- Two Standard Post Heights 2-3/8"
- Available in Four Standard Colors
and Mill Aluminum
1-1/8"

Available Finishes
X1 SLIM SERIES FASCIA MOUNT SLIM POST ONLY
ITEM NO. DESCRIPTION POST HEIGHT/LENGTH
SLF36XX 2-3/8" x 1-1/8" x 36" Slim Post 47"
SLF42XX 2-3/8" x 1-1/8" x 42" Slim Post 53"
Minimum order: 1 each.
W BRZ MB S M
TRAFFIC DARK MATTE SILVER MILL ALUMINUM
WHITE BRONZE BLACK METALLIC (Unpainted)
XX Denotes Finish.
Visit fhc-usa.com to search for
X1 Arrowhead
Enter the Item Number or scan QR code with
AR18 PREMIUM ALUMINUM RAILING SYSTEMS your smartphone for complete product details
