FHC PREMIUM ALUMINUM RAILING SYSTEMS SECTION 1
FHC NEW X9 Spyglass Series Premium Aluminum Railing Systems

FHC X9 Series

Components
90 Degree Horizontal Corner 135 Degree Horizontal Corner

- Factory Welded and - Includes Insert for 2-3/8" - Factory Welded and Powder Coated
Powder Coated Square Post - Includes Insert for 2-3/8" Square Post
- 6" Long Leg Dimensions - 6" Long Leg Dimensions

3"
6"
3" 6"
135°
90°

ITEM NO. X9THXX ITEM NO. X9TH3XX
Minimum Order: 1 Each. Minimum Order: 1 Each.

FHC Top and Bottom Rigid Vinyl
- Dual Durometer Glazing Vinyl - 144" Lengths
- Available in Three Sizes
15/16"
TOP VINYL BOTTOM VINYL 9/16"
ITEM NO. ITEM NO. GLASS THICKNESS
TV14 BV14 1/4" & 5/16" Glass 1-1/16" 15/16"
TV38 BV38 3/8" & 7/16" Glass
TV12 BV12 1/2" & 9/16" Glass Bottom Vinyl
Minimum order: 1 each. Top Vinyl

FHC Top Rail Mounting Bracket FHC Adjustable Mounting

- For Use on 2-3/8" Square Center Posts Bracket For Top Rail
- Mount to Post Using Four TRBS
Top Rail Mounting Screws - For Use on End Posts and Corner Posts
- Mill Finish

ITEM NO. TRBS
Flat Head Screws and
and ITEM NO. TRB1T4
Drive Bit Socket for Use With ITEM NO. HAND
ITEM NO. TRB1 TRB1 Top Rail Bracket TRB1LH Left Hand End Connector
Top Rail Mounting Bracket TRB1RH Right Hand End Connector
Minimum Order: 1 Each. Minimum order: 1 each.
Visit fhc-usa.com to search for
X9 Spyglass FRAMELESS HARDWARE COMPANY LLC
2323 Firestone Blvd. South Gate, CA 90280
Enter the Item Number or scan QR code with Toll Free: (888) 295-4531 | Direct: (323) 968-2031
your smartphone for complete product details 45
Fax: (323) 336-8307 | fhc-usa.com
