FRAMELESS SHOWER DOOR HINGES SECTION 1
Glendale 2-3/16" 15

Frameless Shower Door Hinges

- For 3/8" to 1/2" Tempered Glass Full Back
Plate Shown
- Industry Standard Square
Body Profile 3-1/2" Tall
- Eight Popular Finishes
- Self-Centering Within 15 Degrees Now
of Closing Position 3-1/2" Available In
Polished Brass
- For Use in Residential Bath and
Commercial Hotel Applications NOTE: Dimensions
- Reversible 5 Degree Pivot Pin that Shown are Similar for
Doesn’t Require Special Tools All Glendale Series.
- High Quality Solid Brass Construction
With State-of-the-Art Plating Process

Available Finishes * Available On Select Models Only
INSTALLER'S
FAVORITE!
FHC GMT Power Tip
Drill Bits Item No. GMT
CH BN 0RB MB PN SB BBRZ BR (See Page 144)
POLISHED BRUSHED OIL RUBBED MATTE POLISHED SATIN BRUSHED POLISHED
CHROME NICKEL BRONZE BLACK NICKEL* BRASS* BRONZE* BRASS*
MAXIMUM CAPACITY:
3/8" (10 mm) GLASS 1/2" (12 mm) GLASS Cut-Out Required: Specific Cut-Out Templates
MAXIMUM DOOR Approx. 5 lb/ft 2 Approx. 6.4 lb/ft 2 Available at fhc-usa.com.
CAPACITY
DOOR WEIGHT DOOR WIDTH Includes: Hinge, Glazing Gaskets, Wall Mounting Screws, Allen Head/
Phillips Head Cover Plate Screws, and Fabrication Template.
USING 2 HINGES 80 LBS. (36 kg) 28" (711 mm)
USING 3 HINGES 120 LBS. (54 kg) 32" (813 mm)
NOTE: Do not exceed either maximum weight or width when choosing proper quantity of hinges.

FHC Glendale Glass-to-Wall Hinges for 3/8" to 1/2" Glass

ALLOWS FOR ALLOWS FOR
TIGHTER TIGHTER
WALL CLEARANCE WALL CLEARANCE

ITEM NO. GLENF1XX ITEM NO. GLENS2XX ITEM NO. GLEN03XX
Wall Mount Full Wall Mount Short Wall Mount Offset
Back Plate Hinge Back Plate Hinge Back Plate Hinge
Standard Closing Position Standard Closing Position Standard Closing Position

ITEM NO. GLENF5XX ITEM NO. GLENS5XX ITEM NO. GLEN05XX ITEM NO. GLEN06XX
Wall Mount Full Wall Mount Short Wall Mount Offset Wall Mount Offset
Back Plate Hinge Back Plate Hinge Back Plate Hinge Short Back Plate Hinge
5 Degree Factory Set 5 Degree Factory Set 5 Degree Factory Set Standard Closing
Positive Close Positive Close Positive Close Position
XX = FINISH
visit fhc-usa.com to search for
