FRAMELESS SHOWER DOOR HINGES SECTION 1
Preston 2-1/8"

Frameless Shower Door Hinges

- For 3/8" to 1/2" Tempered Glass
- Industry Standard Beveled Body Profile
3-1/2" Tall With Radius Corners
- Seven Popular Finishes Short Back
Plate Shown
- Self-Centering Within 15 Degrees of
Closing Position 3-1/2"
- For Use in Residential Bath and NOTE: Dimensions
Commercial Hotel Applications Shown are Similar
- Reversible 5 Degree Pivot Pin that for All Preston
Series Hinges.
Doesn’t Require Special Tools
- High Quality Solid Brass Construction
With State-of-the-Art Plating Process

Available Finishes * Available On Select Models Only

INSTALLER'S
FAVORITE!
FHC GMT Power Tip Drill Bits
CH BN 0RB MB PN SB BBRZ Item No. GMT (See Page 144)
POLISHED BRUSHED OIL RUBBED MATTE POLISHED SATIN BRUSHED
CHROME NICKEL BRONZE BLACK NICKEL* BRASS* BRONZE*
MAXIMUM CAPACITY:
Cut-Out Required: Specific Cut-Out Templates
3/8" (10 mm) GLASS 1/2" (12 mm) GLASS
MAXIMUM DOOR Approx. 5 lb/ft 2 Approx. 6.4 lb/ft 2 Available at fhc-usa.com.
CAPACITY Includes: Hinge, Glazing Gaskets, Wall Mounting Screws, Allen Head/
DOOR WEIGHT DOOR WIDTH
Phillips Head Cover Plate Screws, and Fabrication Template.
USING 2 HINGES 80 LBS. (36 kg) 28" (711 mm)
USING 3 HINGES 120 LBS. (54 kg) 32" (813 mm)
NOTE: Do not exceed either maximum weight or width when choosing proper quantity of hinges.
FHC Preston Glass-to-Wall Hinges for 3/8" to 1/2" Glass

ALLOWS FOR
TIGHTER ALLOWS FOR
WALL CLEARANCE TIGHTER
WALL CLEARANCE

ITEM NO. PRESF1XX ITEM NO. PRESS2XX ITEM NO. PRES03XX
Wall Mount Full Wall Mount Short Wall Mount Offset
Back Plate Hinge Back Plate Hinge Back Plate Hinge
Standard Closing Standard Closing Standard Closing
Position Position Position
ITEM NO. PRESF5XX ITEM NO. PRESS5XX ITEM NO. PRES05XX ITEM NO. PRES06XX
Wall Mount Full Wall Mount Short Wall Mount Offset Wall Mount Offset
Back Plate Hinge Back Plate Hinge Back Plate Hinge Short Back Plate Hinge
5 Degree Factory Set 5 Degree Factory Set 5 Degree Factory Set Standard Closing
Positive Close Positive Close Positive Close Position
XX = FINISH
