FRAMELESS SHOWER DOOR HINGES SECTION 1
SECTION 1
Cambria Grande

Frameless Shower Door Pivot Hinges 4-3/4"

- For 1/2" Tempered Glass
- Square Profile Top and H E AV I E R 3/8” 1/2”
FOR
FOR
Bottom, Wall or Header A N D W I D E R D O O R S GLASS GLASS
Mount Pivot Hinge
- Majority of Door's Weight is F O R
Carried on Bottom Pivot Allowing 2-5/8"
for Wider Doors
- Able to be Mounted Inset from Wall,
Enabling Clearance for Towel Bars
- Self-Centering within 15 Degrees
of Closing Position 7/16"
- Seven Popular Finishes ITEM NO. CAMGS01XX
Grande Top or Bottom Mount
Square Pivot Hinge
Available Finishes * Available On Select Models Only
NOTE: Dimensions
Shown are Similar for
All Cambria Grande
Series Pivot Hinges.
CH BN 0RB MB PN SB BBRZ
POLISHED BRUSHED OIL RUBBED MATTE POLISHED SATIN BRUSHED
CHROME NICKEL BRONZE BLACK NICKEL* BRASS* BRONZE*

MAXIMUM CAPACITY:
1/2" (12 mm) GLASS
MAXIMUM DOOR Approx. 6.4 lb/ft 2
CAPACITY
DOOR WEIGHT DOOR WIDTH
USING 2 HINGES 145 LBS. (66 kg) 36" (914 mm)
NOTE: Do not exceed either maximum weight or width when choosing proper quantity of hinges. ITEM NO. CAMGS06XX
Cambria Grande
Cut-Out Required: Specific Cut-Out Templates Available at fhc-usa.com. Top Pivot Hinge
Includes: Hinge, Glazing Gaskets, Wall Mounting Screws, Allen Head/ For Adjustable Header
Phillips Head Cover Plate Screws, and Fabrication Template. (See Page 101)

Non-Handed
Reversible
Wall Bracket

ITEM NO. CAMGS90XX ITEM NO. CAMGS07XX ITEM NO. CAMGS02XX
Cambria Grande L-Mount Cambria Grande Top or Cambria Grande Top
Square Pivot Hinge Bottom Mount Glass-to-Fixed Transom Mount
With Attached Square Pivot Hinge
Reversible U-Clamp
XX = FINISH
visit fhc-usa.com to search for
