FRAMELESS SHOWER DOOR HINGES SECTION 1
Pasadena HD 2-5/8"

Heavy-Duty Frameless
Shower Door Hinges

- For 3/8” to 1/2” Tempered Glass
- For Heavier and Wider Doors, H E AV I E R A N D W I D E R D O O R S
Maximum 145 Pound Rating
- Beveled Profile Wall Mount and F O R
180 Degree Glass-to-Glass Models 4-3/8"
- Seven Popular Finishes ITEM NO. PAS03XX
Wall Mount Offset
- Self-Centering Within 15 Degrees Full Back Plate Hinge
of Closing Position Standard Closing Position
- Solid Brass Construction
- Commonly Used in Residential Bath
and Commercial Hotel Applications

2-5/8"
2-5/8"

4-3/8"
4-3/8"

ITEM NO. PASF1XX ITEM NO. PAS180XX
Wall Mount 180 Degree
Full Back Plate Hinge Glass-to-Glass Hinge
Standard Closing Position Standard Closing Position
Available Finishes * Available On Select Models Only
NOTE: Dimensions
Shown are Similar for All
Pasadena HD Series Hinges.
CH BN 0RB MB PN SB BBRZ
POLISHED BRUSHED OIL RUBBED MATTE POLISHED SATIN BRUSHED
CHROME NICKEL BRONZE BLACK NICKEL* BRASS* BRONZE*

MAXIMUM CAPACITY: Cut-Out Required: Specific
Cut-Out Templates Available
3/8" (10 mm) GLASS OR 1/2" (12 mm) GLASS at fhc-usa.com.
MAXIMUM DOOR Approx. 5 lb/ft 2 Approx. 6.4 lb/ft 2
CAPACITY Includes: Hinge, Glazing
DOOR WEIGHT DOOR WIDTH Gaskets, Wall Mounting
USING 2 HINGES 145 LBS. (65 kg) 40" (1016 mm) Screws, Allen Head/Phillips
Head Cover Plate Screws,
NOTE: Do not exceed either maximum weight or width when choosing proper quantity of hinges. and Fabrication Template.
XX = FINISH
visit fhc-usa.com to search for
