FHC ALUMINUM RAILING SYSTEMS SECTION 1
FHC X1 Series Aluminum Railing

FHC X1 Series

Mounting Hardware & Accessories

FHC AR Top Rail Use for X1 Arrowhead FHC AR Bottom Rail Connector Block
Connector Block Series Only - Use for All AR Bottom Rails

- Used to Connect - Used to Connect
X1 Series Top Rail BRG20XX Bottom
to Post Rail to Post
- Connect to Post Using - Connect to Post
CBS1 Connector Using CBS1 Connector
Block Screws Block Screws
(Sold Separately) (Sold Separately)

ITEM NO. LENGTH ITEM NO. LENGTH
ARCB1 1" ARCB2 1"
ARCB12 12" ARCB22 12"
ARCB241 241" ARCB2241 241"
Minimum order: 1 each. Minimum order: 1 each.

FHC Rail Connecting FHC Tek Screws FHC Surface Mount
Block Screws - #8 x 3/4" Self-Drilling Screw Stanchion 10" Tall

- Used to Connect Bottom Rail
- #10 x 2" Long to Connector Block - Welded 5" x 5" Base Plate
- Used With ARCB1/ - 50 Per Pack - Used With 2-3/8" Square AR Posts
ARCB2 Connector - Available in Four Standard
Blocks Colors and Mill Aluminum
- 50 Per Pack ITEM NO. CBS1 ITEM NO. TKS1 - Custom Lengths and
Minimum Order: 1 Pack. Minimum Order: 1 Pack. Finishes Available

Heavy Duty
FHC Stair Post Fitting Stainless Steel
For Top of Post X1 Series
Top Rail
- Designed to be Used
With X1 Series Top Rail
on Stair Applications
- Available in Four Standard
Colors and Mill Aluminum Post ITEM NO. SM10XX
- Custom Lengths and Minimum Order: 1 Each.
Finishes Available
FHC Core Mount
ITEM NO. X1PFXX Stanchion 10" Tall
Minimum Order: 1 Each.
- Used With 2-3/8"
Square AR Posts
FHC AR Intermediate Bottom - Core Mount Stanchions
Rail Support 12" Long - 10" Tall - Mill Stainless
- Install With Item No. KS50
- Used With BRG20XX and Expansion Cement 10"
BRP20XX Bottom Rails 12" Cut
- Available in Four Standard To
Colors and Mill Aluminum Bottom Rail Size
ITEM NO. ARBS1XX Bottom Rail Grout
Lock
Minimum Order: 1 Each. Support
XX Denotes Finish. ITEM NO. CM10
Minimum Order: 1 Each.
Visit fhc-usa.com to search for
