FHC PREMIUM ALUMINUM RAILING SYSTEMS SECTION 2
FHC ARS Premium Aluminum Railing Systems

FHC Top Rail Infills Available Finishes

For X2 | X3 | X35 | X4 AR Series

- Snap Into Underside of Top Rails
- Four Standard Colors, Plus Mill Aluminum W BRZ MB S M
- 241" Stock Lengths TRAFFIC DARK MATTE SILVER MILL ALUMINUM
WHITE BRONZE BLACK METALLIC (Unpainted)
FHC X2 | X3 | X35 Series FHC X4 Series
Top Rail Infill for Glass Top Rail Infill for Glass

- Designed for 1/4" to 9/16" - Designed for 1/4" to 9/16"
Thick Tempered Glass Thick Tempered Glass
- Available in Four Standard - Available in Four Standard
Colors and Mill Aluminum Colors and Mill Aluminum
- 241" Stock Length - 241" Stock Length

2-1/2"
2-1/2"
1-1/16" 1-1/16"

15/16" ITEM NO. GLS20XX 15/16" ITEM NO. X4GLS20XX
Minimum Order: 1 Each. Minimum Order: 1 Each.

FHC Top Rail Infill For Pickets FHC Pre-Drilled Top Rail Infill
- Simple Snap-In Installation for Picket
- Picket Infill Extrusion for X2, X3,
X35, and X4 Series - Drilled at 4" C.T.C.
- 241" Stock Length - For X2, X3, X35, and X4 Series
- 241" Stock Length
- Simple Snap-In Installation

2-1/2" 2-1/2"

1/8" 1/8"
3/4" ITEM NO. PKT20XX 3/4" ITEM NO. PKTD20XX
Minimum Order: 1 Each. Minimum Order: 1 Each.
FHC Top Rail Glazing Vinyl

- X2, X3, X35, and X4 Series
Top Rigid Vinyl
- Designed to Snap in Before
the Glass is Installed
- For 1/4" to 9/16"
Thick Tempered Glass
ITEM NO. GLASS THICKNESS LENGTH
TV14 1/4" & 5/16" 120"
TV38 3/8" & 7/16" 120"
TV12 1/2" & 9/16" 120"
Minimum order: 1 each.

Visit fhc-usa.com to search for
Top Rail Infills FRAMELESS HARDWARE COMPANY LLC
4361 Firestone Blvd. South Gate, CA 90280
Enter the Item Number or scan QR code with Toll Free: (888) 295-4531 | Direct: (323) 968-2031
your smartphone for complete product details AR31
