FHC X1 Arrowhead Series Premium Aluminum Railing

SBP2
FHC X1 Series - 5" Square Base Plate - Available in Four Standard
Colors and Mill Aluminum
- 3/8" Thick Pre-Drilled Base Plate
Base Plates - Includes BPG5BL Gasket

For 2-3/8" For 2-3/8" Offset
Square Post Square Post
0BP5

C L C L SBP5 C L 0BP5 C L SBP2 0BP2 SBP2 EDIT
3-3/4" 3-3/4"
C L C L
5" SBP5 3-3/4" 5" 3-3/4"

C L C L
5" 5"
ITEM NO. SBP5XX ITEM NO. 0BP5XX
Minimum Order: 1 Each. Minimum Order: 1 Each.

For 2-3/8" X 1-1/8" For 2-3/8" X 1-1/8" Offset
Slim Post Slim Post

C
SBP5 0BP5 SBP5 L SBP2 C L 0BP5 0BP2 SBP2SBP2 EDIT C L 0BP2 C L SBP2 EDIT
3-3/4" 3-3/4"
C L C L
5" 3-3/4" 5" 3-3/4"

C L C L
5" 5"

ITEM NO. SBP2XX ITEM NO. 0BP2XX
Minimum Order: 1 Each. Minimum Order: 1 Each.

FHC Self Adhering Black Gaskets - For 5" Square Base Plates and Fascia Brackets
- Provides Barrier Between Post and Substrate

ITEM NO. BPG5BL ITEM NO. BPG6BL ITEM NO. BPG7BL ITEM NO. BPG8BL
FHC 5" Square Self FHC 6" Black Self Adhering Gaskets FHC 6" Long Black Gaskets for FHC 6" Long Black Gaskets for
Adhering Black Gasket for FMB1, FMB91 FMB51, FMB5 SPF1 Fascia Brackets FMB90 Fascia Brackets
Minimum Order: 1 Each. Fascia Brackets Minimum Order: 1 Set. Minimum Order: 1 Set.
Minimum Order: 1 Set.
Visit fhc-usa.com to search for
X1 Base Plates
Enter the Item Number or scan QR code with
AR26 PREMIUM ALUMINUM RAILING SYSTEMS your smartphone for complete product details
