Page 33 - WEB-AR Aluminum Railing System

ITEM NO. BPS516
Base Plate Screws
FHC PREMIUM ALUMINUM RAILING SYSTEMS SECTION 2
FHC AR Series Aluminum Railing Systems

FHC Rail Mounting Hardware

For X2 | X3 | X35 | X4 AR Series

FHC AR Top and Bottom Rail FHC Base Plate Screws
Connector Block - Secures Base Plate to Post
- 50 Per Pack
- Use for All AR Bottom Rails ITEM NO. BPS516
- Used to Connect Minimum Order: 1 Pack.
BRG20XX Bottom
Rail to Post
- Connect to Post FHC End Cap Screws
Using CBS1 Connector - #8 x 1" End Caps Screws
Block Screws
(Sold Separately) - 50 Per Pack ITEM NO. EC1S
Minimum Order: 1 Pack.
FHC Rail Connecting
Block Screws

- #10 x 2" Long
- Used With ARCB1/ARCB2
Connector Blocks ITEM NO. CBS1
- 50 Per Pack Minimum Order: 1 Pack.
FHC Tek Screws
ITEM NO. LENGTH
ARCB2 1" - #8 x 3/4" Self- Bottom Rail
ARCB22 12" Drilling Screw to Connector
ARCB2241 241" - Used to Block ITEM NO. TKS1
Minimum order: 1 each. Connect - 50 Per Pack Minimum Order: 1 Pack.
FHC Core Mount FHC Surface Mount FHC AR Intermediate
Stanchion 10" Tall Stanchion 10" Tall Bottom Rail Support

- Used With 2-3/8" Square - Welded 5" x 5" Base Plate 12" Long
AR Posts - Used With 2-3/8" Square AR Posts
- Core Mount Stanchions - Available in Four Standard - Used With BRG20XX
and BRP20XX
- 10" Tall - Mill Stainless Colors and Mill Aluminum Bottom Rails
- Install With Item No. KS50 - Custom Lengths and - Available in Four
Expansion Cement Finishes Available Standard Colors Cut To
(See Page 27) and Mill Aluminum Length
Heavy Duty - Cut to Size
Heavy Duty Stainless Steel
Stainless Steel Construction
Construction
Bottom Rail

Aluminum
Bottom Rail
Support
Grout
Lock

ITEM NO. CM10 ITEM NO. SM10XX ITEM NO. ARBS1XX
Minimum Order: 1 Each. Minimum Order: 1 Each. Minimum Order: 1 Each.

Visit fhc-usa.com to search for
Rail Mounting Hardware FRAMELESS HARDWARE COMPANY LLC
4361 Firestone Blvd. South Gate, CA 90280
Enter the Item Number or scan QR code with Toll Free: (888) 295-4531 | Direct: (323) 968-2031
your smartphone for complete product details AR33
Fax: (323) 336-8307 | fhc-usa.com
