FHC PREMIUM ALUMINUM RAILING SYSTEMS SECTION 2
FHC AR Series Aluminum Railing Systems

FHC Corner Brackets

For X2 | X3 | X35 | X4 AR Series

FHC 135 Degree Top Rail FHC 90 Degree Top Rail FHC Top Rail
Mounting Bracket Mounting Bracket Mounting Bracket

- Fascia Mount Bracket for Outside - Fascia Mount Bracket For 2-3/8" - For Use on 2-3/8" Square Posts
135 Degree Post Configurations Square AR Post - Mount to Post Using Four TRBS
- Mill Finish - For 90 Degree Post Configurations Top Rail Mounting Screws
- Mill Finish - Mill Finish

ITEM NO. TRBS
Pan Head for use With
TRB1 Top Rail Bracket

ITEM NO. CB135M ITEM NO. CB90M ITEM NO. TRB1
Minimum Order: 1 Each. Minimum Order: 1 Each. Minimum Order: 1 Each.

FHC Adjustable Mounting FHC Slim Post Top Rail FHC Top Rail Pin and
Bracket For Top Rails Mounting Brackets Splice Plate

- Used to Align AR Top Rails

ITEM NO. HAND
TRB1LH Left Hand End Connector
TRB1RH Right Hand End Connector ITEM NO. TRB2 ITEM NO. SP1N
Minimum order: 1 each. Minimum Order: 1 Each. Minimum Order: 1 Pair.
XX Denotes Finish.
Visit fhc-usa.com to search for
Mounting Brackets FRAMELESS HARDWARE COMPANY LLC
4361 Firestone Blvd. South Gate, CA 90280
Enter the Item Number or scan QR code with Toll Free: (888) 295-4531 | Direct: (323) 968-2031
your smartphone for complete product details AR37
