SECTION 2 FHC PREMIUM ALUMINUM RAILING SYSTEMS
FHC AR Series Premium Aluminum Railing Systems

FHC Bottom Rails

For X2 | X3 | X35 | X4 Series Premium Aluminum Railing Systems

FHC Bottom Rail With Glass Pocket FHC Bottom Picket Rail Extrusion

- 241" Lengths For Picket Infill
- For 1/4" to 9/16" Glass Thickness - 241" Stock Lengths
- Available in Four Standard
Colors and Mill Aluminum - Used With PKT34XX
- Custom Lengths and 3/4" Square Pickets
Finishes Available - Available in Four Standard
Colors and Mill Aluminum
- Custom Lengths and
Finishes Available
15/16"
3/4"

1-3/4" 1-3/4"
1-3/4"
1-3/4"
ITEM NO. SBP5XX
Minimum Order: 1 Each.
1-5/8" 1-5/8"
ITEM NO. BRG20XX ITEM NO. BRP20XX
Minimum Order: 1 Each. Minimum Order: 1 Each.

FHC Pre-Drilled Bottom Rail FHC Bottom Rail Filler For X2
- Pre-Drilled 4-3/4" Center to Center X3 X35 & X4 Series Rail
- 241" Lengths - 241" Stock Lengths
- For Use With PKT34XX
3/4" Square Pickets - Snaps to the Underside of
- Available in Four Standard BRG20 & BRP20 Bottom Rails
Colors and Mill Aluminum - Available in Four Standard
Colors and Mill Aluminum
- Custom Lengths and
Finishes Available
3/4"

1-1/2"
1-3/4"
1-3/4"
1/8"
3/4"
1-3/4"
ITEM NO. BRPD20XX ITEM NO. BRF20XX
Minimum Order: 1 Each. Minimum Order: 1 Each.

FHC Bottom Rigid Vinyl
- X2, X3, X35 and X4 Series
Bottom Rigid Vinyl
- Designed to Snap in Before
the Glass is Installed
- Dual Durometer Glazing Vinyl ITEM NO. GLASS THICKNESS LENGTH
- 144" Lengths BV14 1/4" & 5/16" 120"
3/8" & 7/16"
120"
BV38
BV12 1/2" & 9/16" 120"
Minimum order: 1 each.
Visit fhc-usa.com to search for
Bottom Rails
Enter the Item Number or scan QR code with
AR38 PREMIUM ALUMINUM RAILING SYSTEMS your smartphone for complete product details
