FHC ALUMINUM STOREFRONTS AND ENTRANCES SECTION 1
®
FHC Aluminum Entrance Doors
®
FHC Aluminum
®
Reinforced Door Structure
The 200 Series Narrow
Stile Door Shown
Shear Block
Shear Block
Leveling Screw
Glass
Shear Block
Welded After
Assembly
Hinge Side
TYPICAL TOP SETTING Deep Penetration Internal
BLOCK DETAIL Lead Side Weld at Door Corners
Shear Blocks
Shear Blocks
Typical Spot Weld
After Assembly
Shear Blocks
Top View of Door, Welded
Corners Hinge Side Shown
Bottom View of Door, Welded
Corners Shown
TYPICAL BOTTOM
SETTING BLOCK DETAIL
®
