FHC ALUMINUM STOREFRONTS AND ENTRANCES SECTION 1
®
FHC Aluminum Stock Door and Frame Program
®

FHC Aluminum 200 Series Stock
®
Narrow Stile Door With Offset Pivots
- 2-1/4" Top and 10" Bottom Rails - Heavy-Duty Corner Block
- Supplied with 1/4" Glass Stops Assembly
- 1" Glass Stop Kits Available In - Deep Penetration Welds at
Stock Door Corners
- Offset Pivot, MS Lock, Cylinders - Door Framing Components
and Push/Pull Included Available for All Storefront
Systems Up-and-Over Frame Transom Frame
200 SERIES STOCK 36" X 84" SINGLE DOOR & FRAME WITH OFFSET PIVOTS
STOCK STOCK
STOCK DOOR
ITEM NO. UP-AND-OVER FRAME TRANSOM FRAME
ITEM NO. ITEM NO. LOCK TYPE LATCH SIDE FINISH
D2210R30SA F2FS0R3TSA F2TS0R3TSA MS Lock with Mortise Cylinders Left Satin Anodized
D2210R30DU F2FS0R3TDU F2TS0R3TDU MS Lock with Mortise Cylinders Left Dark Bronze Anodized
D2210L40SA F2FS0L4TSA F2TS0L4TSA MS Lock with Mortise Cylinders Right Satin Anodized
D2210L40DU F2FS0L4TDU F2TS0L4TDU MS Lock with Mortise Cylinders Right Dark Bronze Anodized
Minimum order: 1 each.
200 SERIES STOCK 72" X 84" PAIR OF DOORS & FRAME WITH OFFSET PIVOTS
STOCK PAIR OF DOORS STOCK STOCK
UP-AND-OVER FRAME
TRANSOM FRAME
ITEM NO. ITEM NO. ITEM NO. LOCK TYPE LATCH SIDE FINISH
D2210POSA F2FPOTSA F2TPOTSA 3-Point Lock Center Satin Anodized
D2210PODU F2FPOTDU F2TPOTDU 3-Point Lock Center Dark Bronze Anodized
Minimum order: 1 pair doors, 1 each frames.
200 SERIES STOCK 72" X 84" PAIR OF DOORS & FRAMES WITH OFFSET PIVOTS
STOCK PAIR OF DOORS STOCK STOCK
TRANSOM FRAME
UP-AND-OVER FRAME
ITEM NO. ITEM NO. ITEM NO. LOCK TYPE LATCH SIDE FINISH
D2210PO4SA F2FPO4TSA F2TPO4TSA Flush Bolts & Deadbolt Lock Center Satin Anodized
D2210PO4DU F2FPO4TDU F2TPO4TDU Flush Bolts & Deadbolt Lock Center Dark Bronze Anodized
Minimum order: 1 pair doors, 1 each frames.
Contact FHC Aluminum® Tech Sales at (888) 295-4531
FHC Aluminum 200 Series Stock
®
Narrow Stile Door With Center Pivots
- 2-1/4" Top and 10" Bottom Rails - Deep Penetration Welds at
- Supplied with 1/4” Glass Stops Door Corners
- Back-to-Back Push Bars - Door Framing Components
Included Available for All Storefront
Systems
- Includes Side Load Arm Prep - Use 3010GEF Bottom Pivot
- Heavy-Duty Corner Block and 3010S Side Load Arm
Assembly (Not Included) Up-and-Over Frame Transom Frame

200 SERIES STOCK 36" X 84" SINGLE DOOR & FRAME CENTER PIVOT
STOCK DOOR STOCK FRAME
ITEM NO. ITEM NO. FRAME TYPE LOCK TYPE LATCH SIDE FINISH
D2210R3CSA F2FSCTSA Up-and-Over Frame MS Lock with Mortise Cylinders Left Satin Anodized
D2210R3CDU F2FSCTDU Up-and-Over Frame MS Lock with Mortise Cylinders Left Dark Bronze Anodized
D2210L4CSA F2TSCTSA Transom Frame MS Lock with Mortise Cylinders Right Satin Anodized
D2210L4CDU F2TSCTDU Transom Frame MS Lock with Mortise Cylinders Right Dark Bronze Anodized
Minimum order: 1 each.

200 SERIES STOCK 72" X 84" PAIR OF DOORS & FRAMES CENTER PIVOT
STOCK PAIR OF DOORS STOCK STOCK
TRANSOM FRAME
UP-AND-OVER FRAME
ITEM NO. ITEM NO. ITEM NO. LOCK TYPE LATCH SIDE FINISH
D2210PCSA F2FPCTSA F2TPCTSA 3-Point Lock Center Satin Anodized
D2210PCDU F2FPCTDU F2TPCTDU 3-Point Lock Center Dark Bronze Anodized
Minimum order: 1 pair doors, 1 each frames.
visit fhc-usa.com to search for
Entrances FRAMELESS HARDWARE COMPANY LLC
2323 Firestone Blvd. South Gate, CA 90280
Enter the Item Number or scan QR code with Toll Free: (888) 295-4531 | Direct: (323) 968-2031
your smartphone for complete product details 45
Fax: (323) 336-8307 | fhc-usa.com
