SECTION 7 FHC GLASS GATE SYSTEMS AND HARDWARE
FHC Glass Gate Accessories

FHC Square Back-to-Back Door Pulls FHC Single Door Stop
Header Mounted
- 1" Square Tubing
- For 3/8" to 3/4" Tempered Glass
- Available in 5 Standard Architectural Finishes - Available in Two Sizes of 2" or 6" Long
- Requires 2 Mounting Holes for Installation - Use With (2) #8 Flat Head Fasteners
(Sold Separately)
- Installation Hardware is Included

Hole Size Requirements
1/2" x 1/2" x 2"
• Two 5/8" Diameter Holes

1/2" x 1/2" x 6"
12" CTC PULL
ITEM NO. FINISH
CPSQ12X12BS Brushed Stainless 1/2" X 1/2" X 2" LONG
CPSQ12X12PS Polished Stainless ITEM NO. FINISH
CPSQ10X12SA Satin Anodized 0HDS2BS Brushed Stainless
CPSQ12X12MB Matte Black 0HDS2PS Polished Stainless
CPSQ12X12DU Dark Bronze Anodized 0HDS2DU Dark Bronze Anodized
Minimum Order: 1 Each. 0HDS2SA Satin Anodized
Minimum Order: 1 Each.
24" CTC PULL 1/2" X 1/2" X 6" LONG
ITEM NO. FINISH
CPSQ24X24BS Brushed Stainless ITEM NO. FINISH
CPSQ24X24PS Polished Stainless 0HDS4BS Brushed Stainless
CPSQ24X24SA Satin Anodized 0HDS4PS Polished Stainless
CPSQ24X24MB Matte Black 0HDS4DU Dark Bronze Anodized
CPSQ24X24DU Dark Bronze Anodized 0HDS4SA Satin Anodized
Minimum Order: 1 Each. Minimum Order: 1 Each.
FHC Back-to-Back Pull Handles HES 9600 Surface Mount
®
- 1" Diameter Tubing Electric Strike
- Back-to-Back Round Pull for 3/8" to 3/4" Glass
- Available in Five Standard Architectural Finishes
- Requires Two Mounting Holes for Installation
- 3/4" Thick Stainless
- Installation Hardware is Included
Steel Housing
- Non Handed
- Field Selectable Fail
Hole Size Requirements Safe/Fail Secure
• Two 5/8" Diameter Holes - Tamper Resistant
- Dual Voltage 12 or 24 VDC
- Horizontal Adjustment
10" PULL 12" PULL
ITEM NO. ITEM NO. FINISH
CP10X10BS CP12X12BS Brushed Stainless
CP10X10PS CP12X12PS Polished Stainless
CP10X10SA CP12X12SA Satin Anodized
CP10X10MB CP12X12MB Matte Black
CP10X10DU CP12X12DU Dark Bronze Anodized
Minimum Order: 1 Each.
18" PULL 24" PULL
ITEM NO. ITEM NO. FINISH
CP18X18BS CP24X24BS Brushed Stainless ITEM NO. H9600BS
CP18X18PS CP24X24PS Polished Stainless Minimum Order: 1 Each
CP18X18SA CP24X24SA Satin Anodized
CP18X18MB CP24X24MB Matte Black
CP18X18DU CP24X24DU Dark Bronze Anodized
Minimum Order: 1 Each.

HES is a registered trademark of Henchett Systems, Inc., an ASSA ABLOY Group Company
