ARCHITECTURAL HARDWARE GLASS ENTRANCE SYSTEMS SECTION 1
®
FHC Advance HERC-DOOR 2-1/2" Low Profile Tapered Sidelite Rails

Setting Blocks
(Sold Separately)
See Below
Monolithic or
Laminated
Tempered Glass

1/2"
Setting Block
(Sold Separately) 3/4" 1/4"
See Below
2-7/16"

2-3/16"
Reversible Saddle Reversible Saddle
Set for 3/4" Clearance Set for 1/4" Clearance

1/4"

Reversible
Saddle

U.S. Patent Nos. 11,060,341 and 11,187,323

2-1/2" LOW PROFILE TAPERED SIDELITE END CAPS REPLACEMENT REVERSIBLE SADDLE 120" LENGTH
3/8" & 1/2" GLASS 5/8" & 3/4" GLASS 3/8" & 1/2" GLASS 5/8" & 3/4" GLASS
ITEM NO. ITEM NO. ITEM NO. ITEM NO.
SL25TEC12XX SL25TEC34XX FMSXX120 FMS3XX120
Minimum Order: 1 Each. Minimum Order: 1 Each. Must Ship Common Carrier. Packing and
Handling Charges Will Apply for Orders Less Than 5 Pieces.
Reversible Sidelite
Rail Saddle
2-1/2" Low Profile Tapered Sidelite Rail for 5/8", 3/4", 11/16" or 13/16" Tempered or Laminated Glass

PRODUCT INFO/SPECIFICATIONS:
4"
15/16"
- CSI Format Specifications are Available for Download at fhc-usa.com
- End Caps are Sold Separately (See Above)
- Setting Blocks are Sold Separately (See Below)
- Glazing Gaskets are Included With Each Sidelite Rail
Item No. SB4UC
Setting Block for
2-1/2" LOW PROFILE TAPERED SIDELITE RAILS - STOCK PRODUCTS READY TO SHIP 3/8" or 1/2" Glass 11/16"
Minimum Order 10 Each
5/8" & 11/16" GLASS 3/4" & 13/16" GLASS 5/8" & 11/16" GLASS 3/4" & 13/16" GLASS
120" STOCK LENGTH 120" STOCK LENGTH 240" STOCK LENGTH 240" STOCK LENGTH
ITEM NO. ITEM NO. ITEM NO. ITEM NO.
SL25T58XX120 SL25T34XX120 SL25T58XX240 SL25T34XX240
4"
15/16"
CUSTOM LENGTH AND/OR FINISH ( ) 2-1/2" LOW PROFILE TAPERED SIDELITE RAILS
*
MANUFACTURED TO CUSTOMER SPECIFICATIONS
5/8" & 11/16" GLASS 3/4" & 13/16" GLASS
ITEM NO. ITEM NO.
Item No. SB7UC
Setting Block for
SL25T58XXC SL25T34XXC
5/8" or 3/4" Glass 15/16"
XX Denotes Finish. Minimum Order 10 Each
