SECTION 1 ARCHITECTURAL HARDWARE GLASS ENTRANCE SYSTEMS

FHC Two-Part

Aluminum U-Channel

- For Glass 5/16" to 27/32" Thick
- Unique Ratchet Positioning
- Channels Are Pre-Drilled For Easy Installation
- Two Lengths Available, 118-1/8" and 196-1/8"
- Three PVC Gaskets Available
Depending On Thickness Used
- No Glass Fabrication Required
1-3/16"
- Satin Anodized, Black, and Brushed
Stainless Anodized Finishes Available
- End Caps Available for Finished Look One Channel Accommodates
All Glass Thicknesses With
- Visit fhc-usa.com for Matching Top U-Channels
Unique Ratcheting Feature
Examples Regarding How to Order Channels and Gaskets Shown Below
3/8" 1/2" 3/4"

PVC
Transparent
Profile Gasket
(Sold Separately)
1/2" 1/2" 1/2"

1 x B0520175 Channel 1 x B0520175 Channel 1 x B0520175 Channel
1 x B05201714N Gasket 1 x B05201715N Gasket 1 x B05201714N Gasket Silicone Applied
1 x B05201713N Gasket 1 x B05201714N Gasket 1 x B05201713N Gasket End Cap
(Sold Separately)
TWO PART U-CHANNELS
ITEM NO. DESCRIPTION FINISH
B05201750 Two-Part U-Channel 118-1/8" Long Satin Anodized
B05201750B Two-Part U-Channel 118-1/8" Long Matte Black Installation Assembly
B05201751 Two-Part U-Channel 118-1/8" Long Brushed Stainless Anodized
B05201752 Two-Part U-Channel 196-1/8 Long Satin Anodized 1 PVC 2
B05201750B Two-Part U-Channel 196-1/8 Long Matte Black Gaskets
B05201753 Two-Part U-Channel 196-1/8 Long Brushed Stainless Anodized Mounting
Hole
Minimum Order: 1 Each. Must Ship Common Carrier.
Packing and Handling Charges Will Apply for Orders Less Than 5 Pieces.
END CAPS
ITEM NO. DESCRIPTION FINISH
B05201755 5/16" - 3/8" Glass End Cap Satin Anodized
Setting Blocks Clamp Set Glass and Snap-In
B05201756 1/2" - 9/16" Glass End Cap Satin Anodized
(sold separately) Channel Second Half of Channel
B05201755B 5/16" - 3/8" Glass End Cap Matte Black
B05201756B 1/2" - 9/16" Glass End Cap Matte Black
B05201757 5/16" - 3/8" Glass End Cap Brushed Stainless Anodized 3 4
B05201758 1/2" - 9/16" Glass End Cap Brushed Stainless Anodized
Minimum Order: 1 Each.
PVC TRANSPARENT PROFILE GASKETS
ITEM NO. DESCRIPTION SIZE
B05201713N PVC Transparent Profile Gasket 1/8"W X 196" L
B05201714N PVC Transparent Profile Gasket 5/22"W X 196" L
Push-In Interior Done
B05201715N PVC Transparent Profile Gasket 3/16"W X 393" L Side PVC Gasket
Minimum Order: 1 Each.
visit fhc-usa.com to search for

THE GLAZING SUPPLY COMPANY U-Channel
or enter the Item Number or scan QR code with
32 EXPERIENCE AND INNOV A TION your smartphone for complete product details
