ARCHITECTURAL HARDWARE GLASS ENTRANCE SYSTEMS SECTION 1
®
FHC Advance HERC-DOOR 4" Tapered Sidelite Rails

Monolithic or Setting Blocks
Laminated (Sold Separately)
See Below
Tempered Glass
1/2"

Setting Block
(Sold Separately)
See Below

3-15/16" 3-11/16"

3/4" 1/4"
1/4"
Reversible Saddle Reversible Saddle
Set for 3/4" Clearance Set for 1/4" Clearance
Reversible
Saddle

U.S. Patent Nos. 11,060,341 and 11,187,323
4" TAPERED SIDELITE END CAPS REPLACEMENT REVERSIBLE SADDLE 120" LENGTH
3/8" & 1/2" GLASS 5/8" & 3/4" GLASS 3/8" & 1/2" GLASS 5/8" & 3/4" GLASS
ITEM NO. ITEM NO. ITEM NO. ITEM NO.
SL4TEC12XX SL4TEC34XX FMSXX120 FMS3XX120
Minimum Order: 1 Each. Minimum Order: 1 Each. Must Ship Common Carrier. Packing and
Handling Charges Will Apply for Orders Less Than 5 Pieces.
Reversible Sidelite
Rail Saddle
4" Tapered Sidelite Rail for 5/8", 3/4", 11/16" or 13/16" Tempered or Laminated Glass

PRODUCT INFO/SPECIFICATIONS:
4"
15/16"
- CSI Format Specifications are Available for Download at fhc-usa.com
- End Caps are Sold Separately (See Above)
- Setting Blocks are Sold Separately (See Below)
- Glazing Gaskets are Included With Each Sidelite Rail
Item No. SB4UC
Setting Block for
4" TAPERED SIDELITE RAILS - STOCK PRODUCTS READY TO SHIP 3/8" or 1/2" Glass 11/16"
Minimum Order 10 Each
5/8" & 11/16" GLASS 3/4" & 13/16" GLASS 5/8" & 11/16" GLASS 3/4" & 13/16" GLASS
120" STOCK LENGTH 120" STOCK LENGTH 240" STOCK LENGTH 240" STOCK LENGTH
ITEM NO. ITEM NO. ITEM NO. ITEM NO.
SL4T58XX120 SL4T34XX120 SL4T58XX240 SL4T34XX240
4"
15/16"
CUSTOM LENGTH AND/OR FINISH ( ) 4" TAPERED SIDELITE RAILS
*
MANUFACTURED TO CUSTOMER SPECIFICATION
5/8" & 11/16" GLASS 3/4" & 13/16" GLASS
ITEM NO. ITEM NO.
Item No. SB7UC
Setting Block for
SL4T58XXC SL4T34XXC
5/8" or 3/4" Glass 15/16"
XX Denotes Finish. Minimum Order 10 Each
visit fhc-usa.com to search for
