Page 51 - FAH23R Architectural Hardware Catalog

ARCHITECTURAL HARDWARE GLASS ENTRANCE SYSTEMS SECTION 1
®
FHC Advance HERC-DOOR 10" Square Sidelite Rails

Monolithic or
Laminated
Tempered Glass
5/8"
Setting Block
(Sold Separately)
See Below
Setting Blocks
(Sold Separately)
See Below

10-1/16"
Includes 9-11/16"
Cladding

Reversible 1/4"
Saddle
1/4" 3/4"

Reversible Saddle Reversible Saddle
Set for 3/4" Clearance Set for 1/4" Clearance

U.S. Patent Nos. 11,060,341 and 11,187,323 REPLACEMENT REVERSIBLE SADDLE 120" LENGTH
3/8" & 1/2" GLASS 5/8" & 3/4" GLASS
10" SQUARE SIDELITE END CAPS ITEM NO. ITEM NO.
3/8" & 1/2" GLASS 5/8" & 3/4" GLASS FMSXX120 FMS3XX120
ITEM NO. ITEM NO. Minimum Order: 1 Each. Must Ship Common Carrier. Packing and
Handling Charges Will Apply for Orders Less Than 5 Pieces.
SL10SEC12XX SL10SEC34XX Reversible Sidelite
Minimum Order: 1 Each. Rail Saddle
10" Square Sidelite Rail for 5/8", 3/4", 11/16" or 13/16" Tempered or Laminated Glass

PRODUCT INFO/SPECIFICATIONS:
4"
15/16"
- CSI Format Specifications are Available for Download at fhc-usa.com
- End Caps are Sold Separately (See Above)
- Setting Blocks are Sold Separately (See Below)
- Glazing Gaskets are Included With Each Sidelite Rail
Item No. SB4UC
Setting Block for
10" SQUARE SIDELITE RAILS - STOCK PRODUCTS READY TO SHIP 3/8" or 1/2" Glass 11/16"
Minimum Order 10 Each
5/8" & 11/16" GLASS 3/4" & 13/16" GLASS 5/8" & 11/16" GLASS 3/4" & 13/16" GLASS
120" STOCK LENGTH 120" STOCK LENGTH 240" STOCK LENGTH 240" STOCK LENGTH
ITEM NO. ITEM NO. ITEM NO. ITEM NO.
SL10S58XX120 SL10S34XX120 SL10S58XX240 SL10S34XX240
4"
15/16"
CUSTOM LENGTH AND/OR FINISH ( ) 10" SQUARE SIDELITE RAILS
*
MANUFACTURED TO CUSTOMER SPECIFICATION
5/8" & 11/16" GLASS 3/4" & 13/16" GLASS
ITEM NO. ITEM NO.
Item No. SB7UC
Setting Block for
SL10S58XXC SL10S34XXC
5/8" or 3/4" Glass 15/16"
XX Denotes Finish. Minimum Order 10 Each
visit fhc-usa.com to search for
