ARCHITECTURAL HARDWARE GLASS ENTRANCE SYSTEMS SECTION 1
®
FHC Advance HERC-DOOR 6" Square Sidelite Rails

Setting Blocks
(Sold Separately)
Monolithic or See Below
Laminated
Tempered Glass

9/16"
Setting Block
(Sold Separately)
See Below

6" 5-11/16"

1/4"
1/4" 3/4"

Reversible
Saddle
Reversible Saddle Reversible Saddle
Set for 3/4" Clearance Set for 1/4" Clearance
Chat With FHC On Our Website
to Get Real Time Expert Support
from Knowledgeable Reps

Chat With Us!

U.S. Patent Nos. 11,060,341 and 11,187,323

6" Square Sidelite Rail for 3/8", 1/2" or 19/16" Tempered or Laminated Glass

PRODUCT INFO/SPECIFICATIONS:
- CSI Format Specifications are Available for
Download at fhc-usa.com
- End Caps are Sold Separately
- Setting Blocks are Sold Separately (See Below)
- Glazing Gaskets are Included With Each Sidelite Rail
6" SQUARE SIDELITE END CAPS
3/8" & 1/2" GLASS
ITEM NO.
SL6SEC12XX
Minimum Order: 1 Each. 4"
15/16"

REPLACEMENT REVERSIBLE SADDLE 120" LENGTH
3/8" & 1/2" GLASS Item No. SB4UC
ITEM NO. Setting Block for
11/16"
FMSXX120 3/8" or 1/2" Glass
Minimum Order: 1 Each. Must Ship Common Carrier. Packing and Minimum Order 10 Each
Handling Charges Will Apply for Orders Less Than 5 Pieces.
Reversible Sidelite
Rail Saddle
