SECTION 1 ARCHITECTURAL HARDWARE GLASS ENTRANCE SYSTEMS
FHC-ADVANCE SERIES FRAMELESS
GLASS ENTRANCE SYSTEM
FHC Advance Sidelite
Rail With Reversible Saddle
U.S. Patent Nos. 11,060,341 and 11,187,323
10" Square Sidelite Rail
- For 3/8", 1/2", 5/8" or 3/4" Monolithic Tempered and
9/16", 11/16" or 13/16" Laminated Tempered Glass
- Includes a Reversible Saddle for Standard 1/4" Clearance
or 3/4" Clearance When Thresholds are Required
- All Sidelites Include Glazing Gaskets
- Setting Blocks Are Sold Separately: Item No. SB4UC
(3/8" or 1/2" Glass) Item No. SB7UC (5/8" or 3/4" Glass)
- End Caps and Mounting Anchors are Sold Separately
- Cladding Shipped Loose
- Contact quotes@fhc-usa.com for
Custom Sizes and Finishes
- Available in 120" and
240" Stock Lengths
Saddle
Set for 3/4"
Clearance
Shown
Sidelite Rail Includes
Reversible Saddle
10" Square Sidelite Rail for 3/8", 1/2" or 9/16" Tempered or Laminated Glass
Finishes In Stock * Custom Finishes
BS BRUSHED PS POLISHED SA SATIN MB MATTE DU DARK PB POLISHED SB SATIN 0RB OIL PT CUSTOM PAINT
STAINLESS STAINLESS ANODIZED BLACK BRONZE BRASS BRASS* RUBBED COLOR*
ANODIZED BRONZE*
10" SQUARE SIDELITE RAILS - STOCK PRODUCTS READY TO SHIP
3/8" GLASS 1/2" & 9/16" GLASS 3/8" GLASS 1/2" & 9/16" GLASS
120" STOCK LENGTH 120" STOCK LENGTH 240" STOCK LENGTH 240" STOCK LENGTH
ITEM NO. ITEM NO. ITEM NO. ITEM NO.
SL10S38XX120 SL10S12XX120 SL10S38XX240 SL10S12XX240
CUSTOM LENGTH AND/OR FINISH ( ) 10" SQUARE SIDELITE RAILS Chat With FHC On Our Website
*
MANUFACTURED TO CUSTOMER SPECIFICATION to Get Real Time Expert Support
3/8" GLASS 1/2" & 9/16" GLASS from Knowledgeable Reps
ITEM NO. ITEM NO.
Chat With Us!
SL10S38XXC SL10S12XXC
XX Denotes Finish.
