ARCHITECTURAL HARDWARE GLASS ENTRANCE SYSTEMS SECTION 1
®
FHC Advance HERC-DOOR Headers for Overhead Concealed Door Closers

®
FHC Advance HERC-DOOR Headers - Stock 36" and 72" Lengths
- Custom Sizes Also Available Made to Specifications
for Overhead Concealed Door Closers - Six Architectural Finishes to Choose From
FHC 1-3/4" x 4" 4-3/16" Clad
1-3/4"
Aluminum Door 4" Non-Clad Non-Clad
Headers

1-7/8"
Clad
H4 MODEL

FHC 1-3/4" x 4-1/2" 4-11/16" Clad
Aluminum Door 4-1/2" Non-Clad 1-3/4"
Non-Clad
Headers

1-7/8"
Clad
H45 MODEL

FHC 2" x 4-1/2" 4-11/16" Clad
Aluminum Door 4-1/2" Non-Clad 2"
Non-Clad
Headers

2-1/8"
Clad
H245 MODEL

FHC 2" x 6" 6-3/16" Clad 2"
Non-Clad
Aluminum Door 6" Non-Clad
Headers

2-1/8"
Clad

H6 MODEL

FHC Custom Fabricated HERC-DOOR ®
Headers for Various Applications

- Single or Double Door Headers in
Custom Lengths (Up to 240")
- Add 1 or 2 Glazing Pockets for Sidelites
- Fabrication for Pivots, Electric Concealed
or Surface Mount Locks, Offset Pivots, With Walking Glazing
and Any Other Custom Specification Beam Pivot Pockets
- Custom Finishes Are Available

Flat Filler

U.S. Patent Nos. 11,060,341 and 11,187,323
Door Closer
visit fhc-usa.com to search for Cover Plate
