SECTION 2 FHC FRAMELESS GLASS RAILING CAP RAILS, GASKETS & ACCESSORIES

FHC Cap Rail Edge Protector

FHC CRE12 Aluminum
Cap Rail Edge Protector
5/8"
- For 1/2" to 9/16" Glass
- Protects The Top Edge of 1/16"
Exposed Glass 3/16"
- Adhere With Very High Bond Tape 9/16"
or Silicone ITEM NO. LENGTH FINISH
- Available in Two Architectural CRE12SA 120" Satin Anodized
Finishes and Mill Aluminum
CRE12MB 120" Matte Black
- Sold in 120" Lengths CRE12M 120" Mill Aluminum
Minimum Order: 1 Each. Must Ship Common Carrier.

FHC CREC5 Top Cap Edge Protector for
Railing/Windscreen 7/8"
- For 1/2", 9/16" or 5/8" Glass - Custom Fabrication Available.
- Top Cap Glass Edge Protector Contact FHC Technical Sales See Page 53
for More Information
- Available in Two Architectural Finishes for Glass Deduct
- 304 Alloy Stainless Steel 1-1/2"
- 7/8" x 1-1/2" U-Channel
- End Caps and Glass Rubber Gasket ITEM NO. LENGTH FINISH
Sold Separately
CREC5BS 120" Brushed Stainless
- 120" Long
CREC5PS 120" Polished Stainless
Minimum Order: 1 Each. Must Ship Common Carrier.
FHC CREC7 Top Cap Edge Protector for 1-1/8"
Railing/Windscreen
See Page 53
- For 11/16" or 3/4" Glass - Custom Fabrication Available. for Glass Deduct
- Available in Two Architectural Finishes Contact FHC Technical Sales
for More Information
- 304 Alloy Stainless Steel 1-1/2"
- 1-1/8" x 1-1/2" U-Channel
ITEM NO. LENGTH FINISH
- End Caps and Glass Rubber Gasket CREC7BS 120" Brushed Stainless
Sold Separately
CREC7PS 120" Polished Stainless
Minimum Order: 1 Each. Must Ship Common Carrier.
FHC 90 Degree Horizontal U-Shaped Edge FHC 135 Degree Horizontal U-Shaped Edge
Top Cap Edge Protector Top Cap Protector

- Pre-Fabricated 90 Degree - Custom Fabrication Available, - Pre-Fabricated 135 Degree - Available in Two
Horizontal Corner Contact FHC Technical Sales Horizontal Corner Architectural Finishes
- 6" x 6" O.D. Outer Legs for More Information - 6" x 6" O.D. Outer Legs - Custom Fabrication Available,
- 304 Alloy Stainless Steel - 304 Alloy Stainless Steel Contact FHC Technical Sales for
More Information
- Available in Two
Architectural Finishes
6" 6"
6" 6"

Factory Welded, Factory Welded,
Ground and Finished Ground and Finished
Corners Corners
FOR 1/2", 9/16", FOR 11/16" FOR 1/2", 9/16", FOR 11/16"
& 5/8" GLASS & 3/4" GLASS & 5/8" GLASS & 3/4" GLASS
ITEM NO. ITEM NO. FINISH ITEM NO. ITEM NO. FINISH
CREC5HBS CREC7HBS Brushed Stainless CREC5H3BS CREC7H3BS Brushed Stainless
CREC5HPS CREC7HPS Polished Stainless CREC5H3PS CREC7H3PS Polished Stainless
Minimum Order: 1 Each. Minimum Order: 1 Each.
