SECTION 2 FHC FRAMELESS GLASS RAILING CAP RAILS, GASKETS & ACCESSORIES

FHC Aluminum Cap Rails

FHC CRU7 Aluminum Cap Rail
Matte Black
- For 11/16" Glass
Finish Shown
- Cap Rail For Guardrail Systems Tight Radius
- 1-1/4" x 1-5/16" U-Channel Corners
- 240" Stock Lengths
- Available in Two Architectural Finishes and
Mill Aluminum
- Rubber Gasket, End Caps, Corners and
Sleeves Sold Separately
- Custom Fabrication Available. Contact
FHC Technical Sales For More Information

1-1/4"

Satin Anodized
1-5/16" See Page 51 Finish Shown
for Glass Deduct

Chat With FHC On Our Website ICC
to Get Real Time Expert Support
from Knowledgeable Reps
ITEM NO. LENGTH FINISH
CRU7SA 240" Satin Anodized
CRU7MB 240" Matte Black Chat With Us!
CRU7M 240" Mill Aluminum ESR-4814
Minimum Order: 1 Each. Must Ship Common Carrier.

FHC 90 Degree Horizontal FHC 135 Degree Horizontal
CRU7 Internal Splice Sleeve CRU7 Internal Splice Sleeve

- Internal Connector - Internal Connector
Sleeve for 1-1/4" x 1-5/16" Sleeve for or 1-1/4" x 1-5/16"
Aluminum Cap Rails Aluminum Cap Rails
- Mill Aluminum - Mill Aluminum
- Adhere With LT32629 4" - Adhere With LT32629 Cement
Cement & LT7649 Primer 4" & LT7649 Primer (See Pg. 53)
(See Pg. 53)
4" 4"
90˚
Top View
135˚
Top View

Factory Welded
Factory Welded

FOR CRU7 ALUMINUM CAP RAIL FOR CRU1 ALUMINUM CAP RAIL
ITEM NO. FINISH ITEM NO. FINISH
CRU7S90M Mill Aluminum CRU7S135M Mill Aluminum
Minimum Order: 1 Each. Minimum Order: 1 Each.
ICC-ES is a registered trademark of ICC Evaluation Service LLC.
visit fhc-usa.com to search for
Cap Rail
THE GLAZING SUPPLY COMPANY
Enter the Item Number or scan QR code with
50 EXPERIENCE AND INNOV A TION your smartphone for complete product details
