FHC HANDRAILS, BRACKETS, & COMPONENTS SECTION 5
FHC Handrail Components
FHC 1-1/2" O.D. Aluminum FHC Mill Aluminum Internal
Handrail Tubing Aluminum Rail Connector Sleeve
- 1-1/2" Diameter Aluminum Tube - Use With 1-1/2" Diameter
- .120 Wall Thickness Aluminum Tubing FHC AHR15
- Internal Splices, Endcaps and - 5" Long Internal Connector
Connector Sleeves Sold Separately - Mill Aluminum
- Ahere With LT32629 Cement and
LT7649 Prime (See Page 128)
.120" Wall
Thickness
ITEM NO. FINISH LENGTH
AHR15SA Satin Anodized 236"
AHR15MB Matte Black 236" Item No. AHR15CSM
AHR15M Mill Aluminum 236" Ø1-1/2" Minimum Order: 1 Each
Minimum Order: 1 Each.
FHC 12" X 2-3/4 Wall Return FHC 90 Degree Welded Corner
- For AHR15MB Tubing Open 1-1/2" Diameter .120 Aluminum
Welded End - For AHR15MB Tubing
End Cap
2-3/4" 4" 4"
12"
90°
Item No. AHR15RMB Item No. AHR15HMB
Minimum Order: 1 Each Minimum Order: 1 Each
FHC Aluminum Handrail Tubing FHC Aluminum Handrail Tubing
Internal 90 Degree Connector Sleeve Internal 135 Degree Connector Sleeve
- Internal Connector Sleeve Factory Welded
for 1-1/2" Handrail - Internal Connector Sleeve Factory Welded
for 1-1/2" Handrail
- Mill Aluminum - Mill Aluminum
- Use Item No. LT32629 Metal Contact - Use Item No. LT32629 Metal Contact
Cement and Item No. LT7649 Primer Cement and Item No. LT7649 Primer
for Attachment (See Page 128) for Attachment (See Page 128)
4" 4"
4" 4"
Item No. AHR1S90M Item No. AHR1S135M
Minimum Order: 1 Each 135° Minimum Order: 1 Each
90°
FHC Aluminum Handrail Tubing FHC Aluminum Handrail
Internal 147 Degree Connector Sleeve Tubing End Caps 1/8"
- Internal Connector Sleeve Factory Welded - End Caps for 1-1/2" Aluminum Tubing
for 1-1/2" Aluminum Handrail AHR
- Use Item No. LT32629 Metal Contact
- Mill Aluminum Cement and Item No. LT7649 Primer
- Use Item No. LT32629 Metal for Attachment
Contact Cement 4" 4"
and Item No. LT7649 Primer ITEM NO. FINISH
for Attachment AHR15ECSA Satin Anodized
AHR15ECMB Matte Black
Item No. AHR1S147M 147° AHR15ECM Mill Aluminum
Minimum Order: 1 Each
Minimum Order: 1 Each.
