SECTION 5 FHC HANDRAILS, BRACKETS, & COMPONENTS
FHC Handrail Components

FHC Stainless Steel FHC Stainless Steel
12"
Flange, Stanchion, Internal Flange Cover
Post
and Cover Stanchion - Flange Cover Plate Only
- 12" Tall Internal Steel Stanchion - 4-3/16" Diameter
With Floor Mount Plate - For Use With
- For Use With THR15 1-1/2" Diameter 1-1/2" Outside
Tubing With .050" Wall Thickness 12" Diameter Tubing
1"
- Includes Stainless Steel Cover Plate Tall
- Use Item No. LT32629 Metal Cover
Contact Cement and Item No. Plate
LT7649 Primer for Attachment
(See Page 128) Base
Flange 4-3/16"

ITEM NO. FINISH ITEM NO. FINISH
THR15XBS Brushed Stainless THR15XCBS Brushed Stainless
THR15XPS Polished Stainless THR15XCPS Polished Stainless
3-1/2"
Minimum Order: 1 Each. Minimum Order: 1 Each.
Base
FHC Stainless Steel FHC Concealed Mounting Base
Floor Socket Removable Cap - Use With 1-1/2" Diameter
With Cap 3-11/16" Stainless Tubing FHC 1-7/16"
Item No. THR15 for Concealed
Mounting
- Use With 1-1/2" Diam- - Mill Stainless Steel
eter Handrail Fittings - Drilled & Tapped 5/16"-18
- Floor Socket With (One Side Only)
Removable Cap
3-5/8" - Use Item No. LT32629 Metal 3"
Contact Cement and Item
No. LT7649 Primer
for Attachment
(See Page 128)

ITEM NO. FINISH
THR15FSBS Brushed Stainless Item No. THR15CMB
THR15FSPS Polished Stainless Minimum Order: 1 Each
Minimum Order: 1 Each.
FHC Stainless Steel FHC Connector Sleeves
Straight Saddle 2-13/16" - Use with 1-1/2" Diameter
Stainless Tubing FHC Item
- For Use With No. THR15
THR15 1-1/2" - 5" Long Internal Connector
Diameter
Handrail .050" - Mill Stainless Steel
Wall Thickness - Use Item No. LT32629
Metal Contact Cement and
2" Item No. LT7649 Primer
for Attachment
(See Page 128)

ITEM NO. FINISH
THR15VBS Brushed Stainless Item No. THR15CSS
THR15VPS Polished Stainless Minimum Order: 1 Each
Minimum Order: 1 Each.

Visit fhc-usa.com to search for
THE GLAZING SUPPLY COMPANY Handrail Components

124 EXPERIENCE AND INNOV A TION Enter the Item Number or scan QR code with
your smartphone for complete product details
