FHC FRAMELESS GLASS FENCE HARDWARE SECTION 6
®
FHC GrandVue Frameless Glass Wall Systems
FHC GrandVue Series Pressure
Fit End Glass Clamp NO
1-3/4"
- 1-3/4" X 3-1/2" Low Profile GLASS
Heavy Duty Design
- Designed For Use with 1/2" to 9/16" and 3/4" to FABRICATION
13/16" Monolithic or Laminated Tempered Glass REQUIRED
- Great For Railing, Glass Wall Systems,
and Windbreaks 3-1/2"
- No Glass Fabrication Required ITEM NO. FINISH GLASS THICKNESS
- Can Be Mounted to Square Posts and GV12EBS Brushed Stainless 1/2" to 9/16"
Flat Mounting Substrates GV34EBS Brushed Stainless 3/4" to 13/16"
- High Quality 316 Grade Stainless GV12EPS Polished Stainless 1/2" to 9/16"
Steel Construction GV34EPS Polished Stainless 3/4" to 13/16"
Minimum order: 1 each.
FHC GrandVue Series Pressure FHC GrandVue Series Pressure
Fit Left End Bottom Glass Clamp Fit Right End Bottom Glass Clamp

1-3/4"
1-3/4"

3-1/2"
3-1/2"

ITEM NO. FINISH GLASS THICKNESS ITEM NO. FINISH GLASS THICKNESS
GV12LEBS Brushed Stainless 1/2" to 9/16" GV12REBS Brushed Stainless 1/2" to 9/16"
GV34LEBS Brushed Stainless 3/4" to 13/16" GV34REBS Brushed Stainless 3/4" to 13/16"
GV12LEPS Polished Stainless 1/2" to 9/16" GV12REPS Polished Stainless 1/2" to 9/16"
GV34LEPS Polished Stainless 3/4" to 13/16" GV34REPS Polished Stainless 3/4" to 13/16"
Minimum order: 1 each. Minimum order: 1 each.
FHC GrandVue Series Pressure FHC GrandVue Series Pressure
Fit Center Glass Clamp Fit Bottom Center Glass Clamp

2-1/2" 2-1/2"

3-1/2" 3-1/2"

ITEM NO. FINISH GLASS THICKNESS ITEM NO. FINISH GLASS THICKNESS
GV12CBS Brushed Stainless 1/2" to 9/16" GV12BCBS Brushed Stainless 1/2" to 9/16"
GV34CBS Brushed Stainless 3/4" to 13/16" GV34BCBS Brushed Stainless 3/4" to 13/16"
GV12CPS Polished Stainless 1/2" to 9/16" GV12BCPS Polished Stainless 1/2" to 9/16"
GV34CPS Polished Stainless 3/4" to 13/16" GV34BCPS Polished Stainless 3/4" to 13/16"
Minimum order: 1 each. Minimum order: 1 each.
Visit fhc-usa.com to search for
Grandvue FRAMELESS HARDWARE COMPANY LLC
2323 Firestone Blvd. South Gate, CA 90280
Enter the Item Number or scan QR code with Toll Free: (888) 295-4531 | Direct: (323) 968-2031
your smartphone for complete product details 135
