FHC AW SERIES PREMIUM ALUMINUM WINDSCREEN & GLASS FENCING SYSTEMS SECTION 2
FHC AW Series Premium Aluminum Windscreen Systems

FHC AW Series

Square End Post Kits With Pocket Filler 2

- 6005A-T61 Aluminum 1
- 2-3/8" Square Post
- Five Standard Post Heights
- Includes Pocket Filler,
Post and Top Cap
- Available in Four Standard
Colors and Mill Aluminum
- Top Rail, Bottom Rail, Base
Plate, Washers and Buttons, 3
Stanchion and Glazing Vinyl
Sold Separately
- Custom Heights and
Finishes Available KIT COMPONENTS
1 TC2XX Top Cap for 2-3/8" Square Post
36" Post Kit 42" Post Kit A36CKXX
A42CKXX
ITEM NO. A36EKXX ITEM NO. A42EKXX 2 A48CKXX One Post of the Selected Height
A60CKXX
End Post Kit 36" Tall End Post Kit 42" Tall A72CKXX
Minimum Order: 1 Each. Minimum Order: 1 Each.
WPF36XX One Pocket Filler of the
WPF48XX
48" Post Kit 60" Post Kit 3 WPF60XX Selected Height
WPF72XX
ITEM NO. A48EKXX ITEM NO. A60EKXX
End Post Kit 48" Tall End Post Kit 60" Tall WORKS WITH
Minimum Order: 1 Each. Minimum Order: 1 Each. SBP5XX 5" Square Base Plate
AWCM1 Core Mount Stanchion for Posts up to 60"
72" Post Kit
AWCM2 Core Mount Stanchion for Posts up to 72"
ITEM NO. A72EKXX AWST1XX Surface Mount Stanchion for Posts up
to 48"
End Post Kit 72" Tall Surface Mount Stanchion for Posts From
Minimum Order: 1 Each. AWST2XX 48" to 72"
SURFACE MOUNT CORE MOUNT
GV14BL Rigid Vinyl for Ends and Center
GV38BL AW Windscreen Post
GV12BL (Sold Separately)
Pocket Filler FHC Heavy-Duty Square

- Fits Into AW Series Center Post Only
180 Degree End/Center
Post Extrusions - 6005A-T61 Aluminum
- Available in Four - 2-3/8" Square Post
Standard Colors - Available in Four Standard
and Mill Aluminum Colors and Mill Aluminum
- Custom Lengths and - Custom Heights and
Finishes Available Finishes Available .100 Wall
Thickness
FHC AW SERIES 180 DEGREE END/CENTER POSTS
ITEM NO. LENGTH ITEM NO. POST HEIGHT/LENGTH
WPF36XX 36" AW36XX 36" Tall
WPF48XX 48" AW42XX 42" Tall
WPF60XX 60" AW48XX 48" Tall 2-3/8" 15/16" 7/8"
WPF72XX 72" AW60XX 60" Tall
WPF240XX 240" AW72XX 72" Tall
Minimum order: 1 each. AW20XX 241" Long
Minimum order: 1 each.
XX Denotes Finish. 2-3/8"
AW 180° POST AW 135° POST AW 90° POST
