FHC AW SERIES PREMIUM ALUMINUM WINDSCREEN & GLASS FENCING SYSTEMS SECTION 2
FHC AW Series Premium Aluminum Windscreen Systems

FHC AW Series 2

Square 135 Degree Windscreen Post Kits

- For 135 Degree Corner Post 1
- 6005A-T61 Aluminum
- Five Standard Post Heights
- Includes Post and Top Cap
- Available in Four Standard
Colors and Mill Aluminum
- Top Rail, Bottom Rail, Base
Plate, Washers and Buttons,
and Glazing Vinyl
Sold Separately
- Custom Heights and
Finishes Available
KIT COMPONENTS
1 TC135XX Top Cap for 135˚ Square Post
A365KXX
36" Post Kit 42" Post Kit A425KXX
2 A485KXX One Post of the Selected Height
ITEM NO. A365KXX ITEM NO. A425KXX A605KXX
A725KXX
135° Post Kit 36" Tall 135° Post Kit 42" Tall
Minimum Order: 1 Each. Minimum Order: 1 Each.
WORKS WITH
48" Post Kit 60" Post Kit SBP5XX 5" Square Base Plate
ITEM NO. A485KXX ITEM NO. A605KXX AWCM1 Core Mount Stanchion for Posts up to 60"
135° Post Kit 48" Tall 135° Post Kit 60" Tall AWCM2 Core Mount Stanchion for Posts up to 72"
Minimum Order: 1 Each. Minimum Order: 1 Each.
AWST1XX Surface Mount Stanchion for Posts up to 48"
72" Post Kit AWST2XX Surface Mount Stanchion for Posts From
48" to 72"
BV14 Rigid Vinyl for 135 Degree
ITEM NO. A725KXX BV38 AW Windscreen Post
135° Post Kit 72" Tall BV12 (Sold Separately)
Minimum Order: 1 Each.
SURFACE MOUNT CORE MOUNT
FHC 135Degree Post Only

- 6005A-T61 Aluminum
.100 Wall
- Available in Four Standard 7/8" Thickness
Colors and Mill Aluminum 1-15/16"
- Custom Heights and
Finishes Available

1-15/16" 15/16" 2-3/8"

Available Finishes AW 180° POST AW 135° POST AW 90° POST
FHC AW SERIES 135 DEGREE POSTS
ITEM NO. POST HEIGHT/LENGTH
AW536XX 36" Tall
AW542XX 42" Tall
AW548XX 48" Tall
W BRZ MB S M
TRAFFIC DARK MATTE SILVER MILL ALUMINUM AW560XX 60" Tall
WHITE BRONZE BLACK METALLIC (Unpainted) AW572XX 72" Tall
AW520XX 241" Long
XX Denotes Finish. Minimum order: 1 each.
Visit fhc-usa.com to search for
Windscreen Posts FRAMELESS HARDWARE COMPANY LLC
2323 Firestone Blvd. South Gate, CA 90280
Enter the Item Number or scan QR code with Toll Free: (888) 295-4531 | Direct: (323) 968-2031
your smartphone for complete product details 75
Fax: (323) 336-8307 | fhc-usa.com
