SECTION 1
FRAMELESS SHOWER DOOR HINGES SECTION 1
Junior Preston

Frameless Shower Door Hinges 1-13/16"

- For 1/4" Tempered Glass FOR USE ONLY MONOLITHIC
- Beveled Body Profile 1/4 z TEMPERED GLASS
GLASS
- Solid Brass Construction Full Back
- Preset 5 Degree Pivot Pin - Self-Centering Within Plate Shown
On Select Models 15 Degrees of Closing 3"
- Available in Five Finishes Position
NOTE:
Dimensions
Shown are
Similar for All
MAXIMUM CAPACITY: Jr. Preston
Series Hinges.
1/4" (6 mm) GLASS
MAXIMUM DOOR Approx. 3 lb/ft 2 Available Finishes
CAPACITY
DOOR WEIGHT DOOR WIDTH
USING 2 HINGES 55 LBS. (25 kg) 32" (813 mm)
USING 3 HINGES 85 LBS. (38.6 kg) 36" (914 mm)
NOTE: Do not exceed either maximum weight or width when choosing proper quantity of hinges. CH BN 0RB MB SB
POLISHED BRUSHED OIL RUBBED MATTE SATIN
CHROME NICKEL BRONZE BLACK BRASS*

FHC Junior Preston Series Hinges for 1/4" Glass

ITEM NO. JRPRESF5XX ITEM NO. JRPRES05XX
Wall Mount Wall Mount
Full Back Plate Hinge Offset Back Plate Hinge
5 Degree Factory Set 5 Degree Factory Set
Positive Close Positive Close

ITEM NO. JRPRES180XX ITEM NO. JRPRES135XX ITEM NO. JRPRES90XX
180 Degree 135 Degree 90 Degree
Glass-to-Glass Hinge Glass-to-Glass Hinge Glass-to-Glass Hinge
Standard Closing Position Standard Closing Position Standard Closing Position

XX = FINISH
visit fhc-usa.com to search for
Junior Preston P.O. Box 1906 South Gate, CA 90280
Toll Free: (888) 295-4531 | Direct: (323) 968-2031
Enter the Item Number or scan QR code with
your smartphone for complete product details Fax: (323) 336-8307 | fhc-usa.com 019
