SECTION 1
FRAMELESS SHOWER DOOR HINGES SECTION 1
FHC Venice Series Frameless Shower Door Hinges

FHC Venice Adjustable Hinges
for 3/8'' to 1/2'' Glass

Our NEW Adjustable Hinges allow for
any closed angle up to 90 degrees. The
desired closed position is achieved after
the door is hung, by loosening the Allen
Set Screws, then moving the door into
the correct closed position. Next, tighten
the Allen Set Screws and the door will Adjustable Allen
2 Set Screws
self-center to the new angle. Adjustable (Backside of Hinge)
Hinges swing both inwards and outwards.
1

For Optional "H"
Full Back Plate
3 5 See Page 50.
ITEM NO. VENA4XX ITEM NO. VENAS2XX
Adjustable Wall Mount Adjustable Wall Mount
Full Back Plate Short Back Plate Hinge
Adjustable Closing Position Adjustable Closing Position

4

ITEM NO. VENA135XX ITEM NO. VENA05XX
Adjustable 135 Degree Adjustable Wall Mount
Glass-to-Glass Hinge Offset Back Plate Hinge
1 Venice Short 4 Bottom Wipes Adjustable Closing Position
Back Plate Hinge (See Page 108) Adjustable Closing Position
(See Page 024)
5 Heavy-Duty Square
2 90 Degree Slip Fit Glass Clamp
Glass Clamps (See Page 085)
(See Page 094)
3 Back-to-Back
Mitered Pull Handle
(See Page 057) ITEM NO.VEN180AXX
Adjustable 180 Degree
Glass-to-Glass Hinge
Standard Closing Position

XX = FINISH
visit fhc-usa.com to search for
Venice P.O. Box 1906 South Gate, CA 90280
Toll Free: (888) 295-4531 | Direct: (323) 968-2031
Enter the Item Number or scan QR code with
your smartphone for complete product details Fax: (323) 336-8307 | fhc-usa.com 023
