SECTION 1
FRAMELESS SHOWER DOOR HINGES SECTION 1

FHC Carolina Adjustable Hinges
for 3/8" to 1/2" Glass
Our NEW Adjustable Hinges allow for any closed angle up to 90
degrees. The desired closed position is achieved after the door is
hung, by loosening the Allen Set Screws, then moving the door into
the correct closed position. Next, tighten the Allen Set Screws and
the door will self-center to the new angle. Adjustable Hinges swing
both inwards and outwards.

1

Adjustable Allen
Set Screws
(Backside of Hinge)

2
3

ITEM NO. CLNA4XX ITEM NO. CLNAS2XX
Adjustable Wall Mount Adjustable Wall Mount
Full Back Plate Short Back Plate Hinge
Adjustable Closing Position Adjustable Closing Position

4

1 Wall Mount Full Back 3 Classic Deep
Plate Beveled U-Channel
Glass-to-Wall Hinge (See Page 097)
(See Page 027)
4 Bottom Wipes
2 Back-to-Back (See Page 108)
Tubular Pull Handle
(See Page 056)

ITEM NO. CLNA135XX ITEM NO. CLNA02XX
Adjustable 135 Degree Adjustable Wall Mount
Glass-to-Glass Hinge Offset Back Plate Hinge
Adjustable Closing Position Adjustable Closing Position

XX = FINISH
