FRAMELESS SHOWER DOOR HINGES SECTION 1
Belgrade HD H E AV I E R A N D W I D E R D O O R S

Heavy-Duty Frameless F O R
Shower Door Hinges 2-5/16"
- For 3/8" to 1/2" Tempered Glass 2-15/16"
- For Wider Doors Up to 39"
- Square Profile Wall Mount and
180 Degree Glass-to-Glass Models
- Cover Plates Conceal Fasteners
ITEM NO. BELA03XX
- Recessed Gaskets are Glued in Place 2-15/16" Wall Mount Offset
- Adjustable Self-Centering Location Back Plate Adjustable
Hinge With Covers
(Rear View)
- Can be Adjusted After Door is Installed
- Cover Plates are Held in Place with
Magnets and/or High-Bond Tape
- Seven Popular Finishes
- Commonly Used in Residential Bath
and Commercial Hotel Applications
4-7/8"

2-15/16"

Magnetic
Cover Plates
Conceal
Fasterners
ITEM NO. BELA180XX
180 Degree Glass-to-Glass
Adjustable Hinge With Covers

Available Finishes * Available On Select Models Only
NOTE: Dimensions
Shown are Similar for All
Belgrade HD Series Hinges.

CH BN 0RB MB PN SB BBRZ
POLISHED BRUSHED OIL RUBBED MATTE POLISHED SATIN BRUSHED
CHROME NICKEL BRONZE BLACK NICKEL* BRASS* BRONZE*
MAXIMUM CAPACITY: Cut-Out Required: Specific
Cut-Out Templates Available
3/8" (10 mm) GLASS 1/2" (12 mm) GLASS at fhc-usa.com.
MAXIMUM DOOR Approx. 5 lb/ft 2 OR Approx. 6.4 lb/ft 2
CAPACITY Includes: Hinge, Glazing
DOOR WEIGHT DOOR WIDTH Gaskets, Wall Mounting
Screws, Allen Head/Phillips
USING 2 HINGES 110 LBS. (50 kg) 39" (991 mm)
Head Cover Plate Screws,
NOTE: Do not exceed either maximum weight or width when choosing proper quantity of hinges. Magnetic Cover Plates
and Fabrication Template.
XX = FINISH
visit fhc-usa.com to search for
