FHC Advance HERC-DOOR 2-1/2" Low Profile Tapered Door Rails

Top
HERC-DOOR ®
Monolithic Tempered Rail
or Laminated Glass
Each FHC Door Rail U.S. Patent No. 11,060,341
is Factory Designed Dual-Inclined Bearing
to Allow for Vertical Surface Controls
Adjustment of Plus Angularity and Self
1/16" or Minus 1/16" Centering of the Rail
With Our Included Door U.S. Patent No. 11,187,323
Rail Setting Blocks. Unitizing Clamping Gasket
Solid One Piece
Rail Housing Cladding Included on Stainless
Steel and Brass Finishes
2-1/2"
2-1/4" Overall Deduction
1-7/8" Glass Deduction
(Includes 3/8" Standard
Clearance)
3/8" Clearance
Standard
Optional
Weatherstripping
FHC Low Profile
Seal Sold Separately Rails are Factory
Item No. RWS36
Prepped Directly
to Door Rail
Bottom
HERC-DOOR®
Rail
60 Degree Elevation
A.D.A Compliant
Tapered Top Edge

New Innovative Built-In
Anti-Clamshell Pad
Prevents Chipped Glass U.S. Patent Nos. 11,060,341 and 11,187,323
Corners During Installation

2-1/2" Low Profile Tapered Door Rail for 5/8", 3/4", 11/16" or 13/16" Tempered or Laminated Glass

PRODUCT INFO/SPECIFICATIONS:
Chat With FHC On Our Website
- CSI Format Specifications are Available for Download at fhc-usa.com to Get Real Time Expert Support
- End Caps are Included with Every Door Rail from Knowledgeable Reps
- Door Rails With Locks are Supplied Prepped and Installed, Keyed Cylinders, and
Thumbturns are Sold Separately
- FHC Follows GANA Guidelines for Maximum Door Height and Widths. Chat With Us!
Reference the FHC HERC-DOOR Sizing Guidelines.
®
- For Replacement End Caps, visit fhc-usa.com and search for Item No. R25TEC
2-1/2" LOW PROFILE TAPERED DOOR RAILS 35-3/4" LENGTH - STOCK PRODUCTS READY TO SHIP
FOR 5/8" & 11/16" GLASS FOR 5/8" & 11/16" GLASS FOR 3/4" & 13/16" GLASS FOR 3/4" & 13/16" GLASS
WITHOUT LOCK WITH LOCK WITHOUT LOCK WITH LOCK
ITEM NO. ITEM NO. ITEM NO. ITEM NO.
R25T58XX R25T58XXL R25T34XX R25T34XXL

CUSTOM LENGTH AND/OR FINISH ( ) 2-1/2" LOW PROFILE TAPERED DOOR RAILS - MANUFACTURED TO CUSTOMER SPECIFICATIONS
*
FOR 5/8" & 11/16" GLASS FOR 5/8" & 11/16" GLASS FOR 3/4" & 13/16" GLASS FOR 3/4" & 13/16" GLASS
WITHOUT LOCK WITH LOCK WITHOUT LOCK WITH LOCK
ITEM NO. ITEM NO. ITEM NO. ITEM NO.
R25T58XXC R25T58XXLC R25T34XXC R25T34XXLC

XX Denotes Finish.
