SECTION 1                                                 ARCHITECTURAL HARDWARE GLASS ENTRANCE SYSTEMS

                                                   FHC-ADVANCE SERIES FRAMELESS
                                                   GLASS ENTRANCE SYSTEM


                                                   FHC Advance                                     Rail

                                                   4" Tapered Door Rail
               NEW                                 -  U.S. Patent Nos. 11,060,341 and 11,187,323
               INNOVATIVE                          -  Easiest and Fastest Rail to Install in the Industry
               DESIGN                              -  For 3/8", 1/2", 5/8" or 3/4" Monolithic Tempered and
                                                     9/16", 11/16" or 13/16" Laminated Tempered Glass
                                                   -  Class 1 Anodizing UV Stable Finishes
                                                                                                         ®
                                                     That Will Not Fade                        HERC-DOOR  Patch
                                                                                              Fittings Also Available!
                                                   -   Increased Glass Bite
                                                     Improves Holding Strength
                                                     and Aesthetics
                                                   -  Solid One Piece
                                                     Aluminum Housing
                                                   -  State-of-the-Art Solid Forged
                                                     Brass Plated End Caps With
                                                                                       4" Tapered
                                                     Premium Finishes and New
                                                                                       HERC-DOOR  Patch Fitting
                                                                                               ®
                                                     Innovative Anti-Clamshell         (See Pages 58-59)
            Door Rail
         With Lock Shown                             Pad End Cap
                                                   -  Available With or Without Lock
                                                   -  Available In a Wide Range of Architectural Finishes
                                                   -  Accepts Standard Size Mounting Hardware
                                                   - Meets A.D.A. Requirements (Check Local Building Codes)

           DESIGNED & MANUFACTURED BY
          FRAMELESS HARDWARE COMPANY


        4" Tapered Door Rail for 3/8", 1/2" or 9/16" Tempered or Laminated Glass

        Finishes In Stock                                               * Custom Finishes





        BS BRUSHED   PS POLISHED   SA SATIN   MB MATTE    DU DARK   PB POLISHED   SB SATIN   0RB OIL   PT CUSTOM PAINT
        STAINLESS  STAINLESS  ANODIZED    BLACK     BRONZE      BRASS     BRASS*    RUBBED      COLOR*
                                                    ANODIZED                        BRONZE*

         4" TAPERED DOOR RAILS 35-3/4" LENGTH - STOCK PRODUCTS READY TO SHIP
         FOR 3/8" GLASS            FOR 3/8" GLASS            FOR 1/2" & 9/16" GLASS   FOR 1/2" & 9/16" GLASS
         WITHOUT LOCK              WITH LOCK                 WITHOUT LOCK             WITH LOCK
         ITEM NO.                  ITEM NO.                  ITEM NO.                 ITEM NO.
         R4T38XX                   R4T38XXL                  R4T12XX                  R4T12XXL

         CUSTOM LENGTH AND/OR FINISH ( ) 4" TAPERED DOOR RAILS - MANUFACTURED TO CUSTOMER SPECIFICATIONS
                              *
         FOR 3/8" GLASS            FOR 3/8" GLASS            FOR 1/2" & 9/16" GLASS   FOR 1/2" & 9/16" GLASS
         WITHOUT LOCK              WITH LOCK                 WITHOUT LOCK             WITH LOCK
         ITEM NO.                  ITEM NO.                  ITEM NO.                 ITEM NO.
         R4T38XXC                  R4T38XXLC                 R4T12XXC                 R4T12XXLC

        XX Denotes Finish.
                                                                                     visit fhc-usa.com to search for

                                    THE GLAZING SUPPLY COMPANY                       Door Rails
                                                                                     or enter the Item Number or scan QR code with
       14                           EXPERIENCE AND  INNOV A TION                     your smartphone for complete product details




                      4361 Firestone Blvd. South Gate, CA 90280
              Toll Free: (888) 295-4531  |  Direct: (323) 968-2031
                             Fax: (323) 336-8307  |  fhc-usa.com
