ARCHITECTURAL HARDWARE GLASS ENTRANCE SYSTEMS SECTION 1
®
FHC Advance HERC-DOOR 4" Tapered Door Rails
Top
HERC-DOOR ®
Monolithic Tempered Rail
or Laminated Glass
U.S. Patent No. 11,060,341
Dual-Inclined Bearing
Each FHC Door Rail
Surface Controls
is Factory Designed Angularity and Self
to Allow for Vertical
Centering of the Rail
Adjustment of Plus
1/16" or Minus 1/16" U.S. Patent No. 11,187,323
With Our Included Door Unitizing Clamping Gasket
Rail Setting Blocks.
Cladding Included on Stainless
Solid One Piece Steel and Brass Finishes
Rail Housing
Innovative Concealed
Actuation Hardware
PAS Pivot Alignment
System With Hardware Allows for Uninterrupted
4" Hardware Mounting
Mounting Block Allows
3/8" Adjustments
2-7/8" Glass Deduction
3-1/8" Overall Deduction 1/4" Clearance
(Includes 1/4" Standard
Standard
Clearance)
Optional
Weatherstripping
Sold Separately Bottom
Item No. RWS36 HERC-DOOR ®
Rail
60 Degree Elevation
A.D.A Compliant
Tapered Top Edge
New Innovative Built-In
Anti-Clamshell Pad
Prevents Chipped Glass
Corners During Installation U.S. Patent Nos. 11,060,341 and 11,187,323
4" Tapered Door Rail for 5/8", 3/4", 11/16" or 13/16" Tempered or Laminated Glass
PRODUCT INFO/SPECIFICATIONS:
Chat With FHC On Our Website
- CSI Format Specifications are Available for Download at fhc-usa.com to Get Real Time Expert Support
- End Caps are Included with Every Door Rail from Knowledgeable Reps
- Door Rails With Locks are Supplied Prepped and Installed, Keyed Cylinders, and
Thumbturns are Sold Separately
- FHC Follows GANA Guidelines for Maximum Door Height and Widths. Chat With Us!
Reference the FHC HERC-DOOR Sizing Guidelines.
®
- For Replacement End Caps, visit fhc-usa.com and search for Item No. R4TEC
4" TAPERED DOOR RAILS 35-3/4" LENGTH - STOCK PRODUCTS READY TO SHIP
FOR 5/8" & 11/16" GLASS FOR 5/8" & 11/16" GLASS FOR 3/4" & 13/16" GLASS FOR 3/4" & 13/16" GLASS
WITHOUT LOCK WITH LOCK WITHOUT LOCK WITH LOCK
ITEM NO. ITEM NO. ITEM NO. ITEM NO.
R4T58XX R4T58XXL R4T34XX R4T34XXL
CUSTOM LENGTH AND/OR FINISH ( ) 4" TAPERED DOOR RAILS - MANUFACTURED TO CUSTOMER SPECIFICATIONS
*
FOR 5/8" & 11/16" GLASS FOR 5/8" & 11/16" GLASS FOR 3/4" & 13/16" GLASS FOR 3/4" & 13/16" GLASS
WITHOUT LOCK WITH LOCK WITHOUT LOCK WITH LOCK
ITEM NO. ITEM NO. ITEM NO. ITEM NO.
R4T58XXC R4T58XXLC R4T34XXC R4T34XXLC
XX Denotes Finish.
