Page 26 - FAH23R Architectural Hardware Catalog

SECTION 1 ARCHITECTURAL HARDWARE GLASS ENTRANCE SYSTEMS

FHC-ADVANCE SERIES FRAMELESS
GLASS ENTRANCE SYSTEM

FHC Advance Rail

10" Square Door Rail
- U.S. Patent Nos. 11,060,341 and 11,187,323
- New Modern Crisp Corner Design
NEW - Easiest and Fastest Rail to Install in the Industry

INNOVATIVE - For 3/8", 1/2", 5/8" or 3/4" Monolithic Tempered and
DESIGN - Class 1 Anodizing UV Stable Finishes
9/16", 11/16" or 13/16" Laminated Tempered Glass

That Will Not Fade
- Increased Glass Bite Improves

Holding Strength and Aesthetics
- Solid One Piece Aluminum Housing
- State-of-the-Art Solid Forged
DESIGNED & MANUFACTURED BY
Brass Plated End Caps With FRAMELESS HARDWARE COMPANY
Premium Finishes and New
Innovative Anti-Clamshell Pad
End Cap
- Available With or Without Lock
- Available In a Wide Range of
Architectural Finishes
- Accepts Standard Size Mounting Hardware
- Meets A.D.A. Requirements (Check Local Building Codes)

10" Square Door Rail for 3/8", 1/2" or 9/16" Tempered or Laminated Glass

Finishes In Stock * Custom Finishes

BS BRUSHED PS POLISHED SA SATIN MB MATTE DU DARK PB POLISHED SB SATIN 0RB OIL PT CUSTOM PAINT
STAINLESS STAINLESS ANODIZED BLACK BRONZE BRASS BRASS* RUBBED COLOR*
ANODIZED BRONZE*

10" SQUARE DOOR RAILS 35-3/4" LENGTH - STOCK PRODUCTS READY TO SHIP
FOR 3/8" GLASS FOR 3/8" GLASS FOR 1/2" & 9/16" GLASS FOR 1/2" & 9/16" GLASS
WITHOUT LOCK WITH LOCK WITHOUT LOCK WITH LOCK
ITEM NO. ITEM NO. ITEM NO. ITEM NO.
R10S38XX R10S38XXL R10S12XX R10S12XXL

CUSTOM LENGTH AND/OR FINISH ( ) 10" SQUARE DOOR RAILS - MANUFACTURED TO CUSTOMER SPECIFICATIONS
*
FOR 3/8" GLASS FOR 3/8" GLASS FOR 1/2" & 9/16" GLASS FOR 1/2" & 9/16" GLASS
WITHOUT LOCK WITH LOCK WITHOUT LOCK WITH LOCK
ITEM NO. ITEM NO. ITEM NO. ITEM NO.
R10S38XXC R10S38XXLC R10S12XXC R10S12XXLC

XX Denotes Finish.
visit fhc-usa.com to search for

THE GLAZING SUPPLY COMPANY Door Rails
or enter the Item Number or scan QR code with
20 EXPERIENCE AND INNOV A TION your smartphone for complete product details

4361 Firestone Blvd. South Gate, CA 90280
Toll Free: (888) 295-4531 | Direct: (323) 968-2031
Fax: (323) 336-8307 | fhc-usa.com
