Page 28 - FAH23R Architectural Hardware Catalog

SECTION 1 ARCHITECTURAL HARDWARE GLASS ENTRANCE SYSTEMS

FHC Advance "VDS"

Vertical Door Stile

- Featuring U.S. Patent No. 11,187,3212
FHC's Advance Unitizing Gasket,
Making it the Fastest and Easiest to
Install in the Industry
- For Use With 1/2", 9/16", 3/4" or 13/16" Tempered Glass
- Adds Rigidity and Reduces Glass Deflection
- Reduces Drafts and Sound Transmission
- Available in Brushed Stainless, Black/Bronze
Anodized, Polished Brass, Satin Anodized,
and Satin Brass Finishes
- Custom Finishes Available Upon Request
™
- Use With FHC Herc-Door Rails
- Sold in 119-3/4" Stock Lengths, Can Be Cut to Size
Vertical Door Stile Glass Deductions
Door Opening
Net Door Width
5/16" 5/16"

®

13/16"
Glass Width:
Net Door Width Minus 5/8"
Equals Net Glass Width
1/8" 1/8"

119-3/4" LENGTH FHC ADVANCE VDS VERTICAL DOOR STYLE KITS
STOCK PRODUCTS READY TO SHIP
FOR 1/2" & 9/16" GLASS FOR 3/4" & 13/16" GLASS End Cap
ITEM NO. ITEM NO. Retaining Block Attachment
Mounting Screw Scew
VDS12XX VDS34XX
End Cap
Minimum Order: 1 Each. Retaining
Block
CUSTOM LENGTH AND/OR FINISH FHC ADVANCE VDS VERTICAL
DOOR STILE KITS MANUFACTURED TO CUSTOMER SPECIFICATION
FOR 1/2" & 9/16" GLASS FOR 3/4" & 13/16" GLASS
ITEM NO. ITEM NO.
VDS12XXC VDS34XXC
End
Minimum Order: 1 Each. Cap
Available Finishes Chat With FHC On Our Website
* Custom Finish
to Get Real Time Expert Support
from Knowledgeable Reps

Chat With Us!
BS BRUSHED PS POLISHED SA SATIN MB MATTE DU DARK PB POLISHED SB SATIN
STAINLESS STAINLESS ANODIZED BLACK BRONZE BRASS BRASS*
ANODIZED
visit
to search for
fhc-usa.com
visit fhc-usa.com to search for
Patch Door Rails
CREATE V er tical Stiles
THE GLAZING SUPPLY COMPANY CR
or enter the Item Number or scan QR code with
or enter the Item Number or scan QR code with
22 EXPERIENCE AND INNOV A TION your smartphone for complete product details
your smartphone for complete product details
4361 Firestone Blvd. South Gate, CA 90280
Toll Free: (888) 295-4531 | Direct: (323) 968-2031
Fax: (323) 336-8307 | fhc-usa.com
