ARCHITECTURAL HARDWARE GLASS ENTRANCE SYSTEMS SECTION 1
®
FHC Advance HERC-DOOR 10" Square Door Rails

U.S. Patent No.
Monolithic Tempered New Modern
11,060,341 Crisp Corner
or Laminated Glass
Dual-Inclined Bearing Design
Surface Controls
Angularity and Self
Each FHC Door Rail Centering of the Rail
is Factory Designed
to Allow for Vertical U.S. Patent No.
Adjustment of Plus 11,187,323 Unitizing
1/16" or Minus 1/16" Clamping Gasket
With Our Included Door
Rail Setting Blocks.
9-1/8" Overall Deduction
(Includes 1/4" Standard
Clearance)

Solid One Piece Socket Head 10" Bottom
Rail Housing Cap Screw HERC-DOOR ®
Rail
10"
Cladding Included
on Stainless
Steel and Brass
Finishes Elevation
New Innovative Built-In
PAS Pivot Alignment
System With Hardware 8-7/8" Glass Anti-Clamshell Pad
Mounting Block Allows Deduction
3/8" Adjustments Prevents Chipped Glass
Corners During Installation
Optional 1/4"
Weatherstripping Clearance
Seal Sold Separately Standard
Item No. RWS36
U.S. Patent Nos. 11,060,341 and 11,187,323

10" Square Door Rail for 5/8", 3/4", 11/16" or 13/16" Tempered or Laminated Glass

PRODUCT INFO/SPECIFICATIONS:
Chat With FHC On Our Website
- CSI Format Specifications are Available for Download at fhc-usa.com to Get Real Time Expert Support
- End Caps are Included with Every Door Rail from Knowledgeable Reps
- Door Rails With Locks are Supplied Prepped and Installed, Keyed Cylinders, and
Thumbturns are Sold Separately
- FHC Follows GANA Guidelines for Maximum Door Height and Widths. Chat With Us!
®
Reference the FHC HERC-DOOR Sizing Guidelines.
- For Replacement End Caps, visit fhc-usa.com and search for Item No. R10SEC
10" SQUARE DOOR RAILS 35-3/4" LENGTH - STOCK PRODUCTS READY TO SHIP
FOR 5/8" & 11/16" GLASS FOR 5/8" & 11/16" GLASS FOR 3/4" & 13/16" GLASS FOR 3/4" & 13/16" GLASS
WITHOUT LOCK WITH LOCK WITHOUT LOCK WITH LOCK
ITEM NO. ITEM NO. ITEM NO. ITEM NO.
R10S58XX R10S58XXL R10S34XX R10S34XXL

CUSTOM LENGTH AND/OR FINISH 10" SQUARE DOOR RAILS - MANUFACTURED TO CUSTOMER SPECIFICATIONS
*
FOR 5/8" & 11/16" GLASS FOR 5/8" & 11/16" GLASS FOR 3/4" & 13/16" GLASS FOR 3/4" & 13/16" GLASS
WITHOUT LOCK WITH LOCK WITHOUT LOCK WITH LOCK
ITEM NO. ITEM NO. ITEM NO. ITEM NO.
R10S58XXC R10S58XXLC R10S34XXC R10S34XXLC

XX Denotes Finish.
visit fhc-usa.com to search for
