Page 32 - FAH23R Architectural Hardware Catalog

SECTION 1 ARCHITECTURAL HARDWARE GLASS ENTRANCE SYSTEMS

FHC All-Glass Entrance System Channels

FHC 1-7/8" x 11/16" Narrow
Width Shallow Channel for
3/8" or 1/2" Glass
- Available in Five Finishes
- Channel Can Be Recessed in Floor
- 10' and 20' Lengths Available Setting Block
- Includes Gasket for 1/2" Glass Sold Separately
- Custom Lengths and Finishes Also Available (See Below)
- Commonly Used As Sill or Jamb Mullins

STOCK 1-7/8" x 11/16" NARROW WIDTH SHALLOW CHANNEL WITH GASKET
120" STOCK LENGTH 240" STOCK LENGTH
ITEM NO. ITEM NO. FINISH
NWS12BS120 NWS12BS240 Brushed Stainless
NWS12PS120 NWS12PS240 Polished Stainless
NWS12SA120 NWS12SA240 Satin Anodized 11/16"
1-7/8"
NWS12MB120 NWS12MB240 Matte Black
Dimensions Shown
NWS12DU120 NWS12DU240 Dark Bronze Anodized
Minimum Order: 1 Each. Must Ship Common Carrier. Are Without Clad
Packing and Handling Charges Will Apply for Orders Less Than 5 Pieces.
FHC Flat Snap-In Filler FHC End Caps for
Strip for Narrow Width NWS12 Narrow Width
Shallow Channels Shallow Channels

- Simply Snap Into NWS12 - Used With FHC NWS12
Shallow Channel Series Shallow Channels
- 10' Lengths - Screws Are Supplied With
- Available in Five End Caps
Architectural Finishes - Available in Five
Architectural Finishes
10' FLAT SNAP IN FILLER STRIP
ITEM NO. FINISH
ITEM NO. FINISH
NWFS12BS120 Brushed Stainless
NWS12ECBS Brushed Stainless
NWFS12PS120 Polished Stainless
NWS12ECPS Polished Stainless
NWFS12SA120 Satin Anodized
NWS12ECSA Satin Anodized
NWFS12MB120 Matte Black
NWS12ECMB Matte Black
NWFS12DU120 Dark Bronze Anodized
NWS12ECDU Dark Bronze Anodized
Minimum Order: 1 Each. Must Ship Common Carrier.
Packing and Handling Charges Will Apply for Orders Less Than 5 Pieces. Minimum Order: 1 Each.
FHC Neoprene - 80 Durometer Hardness FHC Push-In
- For Shimming Glass in Channels
Setting Blocks - Wide Range of Sizes Available Glazing Gaskets
- 100 Setting Blocks Per Box
- For 3/8" or 1/2" Thick Glass
- Sold in 100' or 500' Rolls
Find More Size Options at - Used for Dry Glazing
FHC-USA.COM & Search for U-Channels and Sidelite Rails
Setting Blocks
1/2"
4"
1/8"
ITEM NO. FOR GLASS TYPE ROLL SIZE
3858SG100 3/8" (10 mm) 100'
3858SG500 3/8" (10 mm) 500'
ITEM NO. NSB579 1234SG100 1/2" (12 mm) 100'
1/8" x 1/2" x 4" Shown 1234SG500 1/2" (12 mm) 500'
Minimum Order 1 Box Minimum Order: 1 Roll.
visit fhc-usa.com to search for

THE GLAZING SUPPLY COMPANY Channels
or enter the Item Number or scan QR code with
26 EXPERIENCE AND INNOV A TION your smartphone for complete product details
