Page 34 - FAH23R Architectural Hardware Catalog

SECTION 1 ARCHITECTURAL HARDWARE GLASS ENTRANCE SYSTEMS

FHC All-Glass Entrance System Channels

FHC 2-1/8" x 7/8" Narrow
Width Shallow Channel for
5/8" or 3/4" Glass
- Available in Five Finishes
- Channel Can Be Recessed in Floor
Setting Block
- 10' and 20' Lengths Available Sold Separately
- Includes Gasket for 3/4" Glass (See Below)
- Custom Lengths and Finishes Also Available

STOCK 2-1/8" x 7/8" NARROW WIDTH SHALLOW CHANNEL WITH GASKET
120" STOCK LENGTH 240" STOCK LENGTH
ITEM NO. ITEM NO. FINISH
NWS34BS120 NWS34BS240 Brushed Stainless
NWS34PS120 NWS34PS240 Polished Stainless
NWS34SA120 NWS34SA240 Satin Anodized 2-1/8" 7/8"
NWS34MB120 NWS34MB240 Matte Black
NWS34DU120 NWS34DU240 Dark Bronze Anodized Dimensions Shown
Minimum Order: 1 Each. Must Ship Common Carrier. Are Without Clad
Packing and Handling Charges Will Apply for Orders Less Than 5 Pieces.
FHC Flat Snap-In Filler FHC End Caps for
Strip for Narrow Width NWS34 Narrow Width
Shallow Channels Shallow Channels

- Simply Snap Into NWS34 - Used With FHC NWS34
Shallow Channel Series Shallow Channels
- 10' Lengths - Cut to Size - Screws Are Supplied With
- Available in Five End Caps
Architectural Finishes - Available in Five
Architectural Finishes
10' FLAT SNAP IN FILLER STRIP
ITEM NO. FINISH ITEM NO. FINISH
NWFS34BS120 Brushed Stainless NWS34ECBS Brushed Stainless
NWFS34PS120 Polished Stainless NWS34ECPS Polished Stainless
NWFS34SA120 Satin Anodized NWS34ECSA Satin Anodized
NWFS34MB120 Matte Black NWS34ECMB Matte Black
NWFS34DU120 Dark Bronze Anodized NWS34ECDU Dark Bronze Anodized
Minimum Order: 1 Each. Must Ship Common Carrier. Minimum Order: 1 each.
Packaging and Handling Charges Will Apply for Orders Less Than 5 Each.
FHC Neoprene - 80 Durometer Hardness FHC Push-In
- For Shimming Glass in Channels
Setting Blocks - Wide Range of Sizes Available Glazing Gaskets
- 100 Setting Blocks Per Box
- For 5/8" or 3/4" Thick Glass
- Sold in 100' or 500' Rolls
Find More Size Options at - Used for Dry Glazing
FHC-USA.COM & Search for U-Channels and Sidelite Rails
Setting Blocks
1/2"
4"
1/8"
ITEM NO. FOR GLASS TYPE ROLL SIZE
3858SG100 5/8" (16 mm) 100'
3858SG500 5/8" (16 mm) 500'
ITEM NO. NSB579 1234SG100 3/4" (19 mm) 100'
1/8" x 1/2" x 4" Shown 1234SG500 3/4" (19 mm) 500'
Minimum Order 1 Box Minimum Order: 1 Roll.
visit fhc-usa.com to search for

THE GLAZING SUPPLY COMPANY Channels
or enter the Item Number or scan QR code with
28 EXPERIENCE AND INNOV A TION your smartphone for complete product details
