ARCHITECTURAL HARDWARE GLASS ENTRANCE SYSTEMS SECTION 1

FHC All-Glass Entrance System Channels

FHC 1-7/8" x 1-5/8" Narrow
Width Deep Channel for
3/8" or 1/2" Glass Setting Block
Sold Separately
- Receives Snap-In Filler, Roll In Glazing (See Below)
Gasket and Top Pivot Block
- Includes Gasket for 1/2" Glass
- 10' and 20' Lengths Available
- Custom Lengths and Finishes Also Available
- Commonly Used As Sill, Jamb, or Head Mullions

STOCK 1-7/8" x 1-5/8" NARROW WIDTH DEEP CHANNEL WITH GASKET
120" STOCK LENGTH 240" STOCK LENGTH
ITEM NO. ITEM NO. FINISH
NWD12BS120 NWD12BS240 Brushed Stainless
NWD12PS120 NWD12PS240 Polished Stainless
NWD12SA120 NWD12SA240 Satin Anodized 1-5/8"
1-7/8"
NWD12MB120 NWD12MB240 Matte Black
Dimensions Shown
NWD12DU120 NWD12DU240 Dark Bronze Anodized
Minimum Order: 1 Each. Must Ship Common Carrier. Are Without Clad
Packing and Handling Charges Will Apply for Orders Less Than 5 Pieces.
FHC Flat Snap-In Filler FHC End Caps for
Strip for Narrow Width NWD12 Narrow Width
Deep Header/Channels Deep Channels

- Simply Snap Into NWD12 - Used With FHC NWD12
Shallow Channel Series Shallow Channels
- 10' Lengths - Screws Are Supplied With
- Available in Five End Caps
Architectural Finishes - Available in Five
Architectural Finishes
10' FLAT SNAP IN FILLER STRIP
ITEM NO. FINISH
ITEM NO. FINISH
NWFS12BS120 Brushed Stainless
NWD12ECBS Brushed Stainless
NWFS12PS120 Polished Stainless
NWD12ECPS Polished Stainless
NWFS12SA120 Satin Anodized
NWD12ECSA Satin Anodized
NWFS12MB120 Matte Black
NWD12ECMB Matte Black
NWFS12DU120 Dark Bronze Anodized
NWD12ECDU Dark Bronze Anodized
Minimum Order: 1 Each. Must Ship Common Carrier.
Packing and Handling Charges Will Apply for Orders Less Than 5 Pieces. Minimum Order: 1 Each.
FHC Aluminum/Neoprene FHC Push-In Glazing Gaskets
Setting Block - For 3/8" or 1/2" Thick Glass
- Supports and Protects 3/8" or - Sold in 100' or 500' Rolls
1/2" Glass in Sidelite Rails or - Used for Dry Glazing
Narrow Width Deep Channels U-Channels and Sidelite Rails
- For Use With Tempered Glass

4"
15/16"

ITEM NO. FOR GLASS TYPE ROLL SIZE
3858SG100 3/8" (10 mm) 100'
3858SG500 3/8" (10 mm) 500'
1234SG100 1/2" (12 mm) 100'
ITEM NO. SB4UC 11/16"
1234SG500 1/2" (12 mm) 500'
Minimum Order 10 Each
Minimum Order: 1 Roll.
