ARCHITECTURAL HARDWARE GLASS ENTRANCE SYSTEMS SECTION 1

FHC All-Glass Entrance System Channels

FHC 2-1/8" x 1-5/8" Narrow
Width Deep Channel for
Setting Block
5/8" or 3/4" Glass Sold Separately
(See Below)
- Receives Snap-In Filler, Roll In Glazing
Gasket and Top Pivot Block
- Includes Gasket for 3/4" Glass
- 10' and 20' Lengths Available
- Custom Lengths and Finishes Also Available

STOCK 2-1/8" x 1-5/8" NARROW WIDTH DEEP CHANNEL WITH GASKET
120" STOCK LENGTH 240" STOCK LENGTH
ITEM NO. ITEM NO. FINISH
NWD34BS120 NWD34BS240 Brushed Stainless
NWD34PS120 NWD34PS240 Polished Stainless
1-5/8"
NWD34SA120 NWD34SA240 Satin Anodized 2-1/8"
NWD34MB120 NWD34MB240 Matte Black
NWD34DU120 NWD34DU240 Dark Bronze Anodized Dimensions Shown
Minimum Order: 1 Each. Must Ship Common Carrier. Are Without Clad
Packing and Handling Charges Will Apply for Orders Less Than 5 Pieces.
FHC Flat Snap-In Filler FHC End Caps for
Strip for Narrow Width NWD34 Narrow Width
Deep Header/Channels Deep Channels

- Simply Snap Into NWD34 - Used With FHC NWD34
Shallow Channel Series Deep Channels
- 10' Lengths - Cut to Size - Screws Are Supplied With
- Available in Five End Caps
Architectural Finishes - Available in Five
Architectural Finishes

10' FLAT SNAP IN FILLER STRIP
ITEM NO. FINISH ITEM NO. FINISH
NWFS34BS120 Brushed Stainless NWD34ECBS Brushed Stainless
NWFS34PS120 Polished Stainless NWD34ECPS Polished Stainless
NWFS34SA120 Satin Anodized NWD34ECSA Satin Anodized
NWFS34MB120 Matte Black NWD34ECMB Matte Black
NWFS34DU120 Dark Bronze Anodized NWD34ECDU Dark Bronze Anodized
Minimum Order: 1 Each. Must Ship Common Carrier. Minimum Order: 1 each.
Packaging and Handling Charges Will Apply for Orders Less Than 5 Each.
FHC Aluminum/Neoprene FHC Push-In Glazing Gaskets
Setting Block - For 5/8" or 3/4" Thick Glass
- Supports and Protects 5/8" or 3/4" - Sold in 100' or 500' Rolls
Glass in Sidelite Rails or Narrow - Used for Dry Glazing
Width Deep Channels U-Channels and Sidelite Rails
- For Use With Tempered Glass

4"
15/16"

ITEM NO. FOR GLASS TYPE ROLL SIZE
3858SG100 5/8" (16 mm) 100'
3858SG500 5/8" (16 mm) 500'
1234SG100 3/4" (19 mm) 100'
ITEM NO. SB7UC 15/16" 1234SG500 3/4" (19 mm) 500'
Minimum Order 10 Each Minimum Order: 1 Roll.
