ARCHITECTURAL RAILING SYSTEMS
FHC Precision Lock Plus Adjustable Glass Railing
®

FHC Precision Lock Plus Glass Locks FHC Precision Lock ®
®
- Allows Up To 2 Degrees Glass Panel Adjustment Aluminum Base Shoe
- Patented Design Allows Easy Access for Adjustment - Compatible With 1/2" - 13/16" Glass
- Packaged 10 Glass Locks Per Box - Easy Adjustment, Does Not Require Special Tools
- Works with Precision Lock Base Shoe - Adjust Glass Panels Up to 2 Degree From Plumb

- Install Glass Locks Every 12" to 14" on Center
- 6063 T5 Aluminum Alloy

- Available in 10' and 20' Base Shoe Lengths

- Glass-Locks, Gaskets, Cladding and
End Caps Sold Separately
3-3/4"
7/8"
7/8"

9/16" Drilled and
Counterbored
2-3/4"
Base Shoe Profile

FHC PRECISION LOCK PLUS ® GLASS-LOCKS FHC PRECISION LOCK ® BASE SHOE
ITEM NO. DESCRIPTION ITEM NO. DESCRIPTION
PL916M Glass-Locks for 1/2" to 9/16" Glass Thickness (.469-.550") PL75M10D Drilled 12" C.T.C. 120" Long
PL1116M Glass-Locks for 5/8"-11/16" Glass Thickness (.569-.726") PL75M20D Drllied 12" C.T.C. 240" Long
PL1316M Glass-Locks for 3/4"-13/16" Glass Thickness (.705-.906") Minimum Order: 1 Each. Must Ship Common Carrier.
Minimum Order: 1 Pack..

FHC Precision Lock Plus ® FHC Precision Lock Plus ®
Traditional Gasket Cladding Gasket

- Used On Applications - Used On Application
Without Cladding With Cladding
- 250' Roll - 100' Role-Installed
- Can Be Pre-Installed On Outside of Shoe
On Outside of Shoe With Cladding
- Tape Applied High Bond Tape
For Applications
Factory Applied
Without Cladding
Innovative
ITEM NO. PLGS250 Pressure Fit ITEM NO. PGASKET5TA Cladding
Design
Minimum Order: 1 Roll. Minimum Order: 1 Roll.

FHC Precision Lock Plus Cladding FHC Precision Lock Plus End Cap
®
®
- Fits PL75 Series Base Shoe and Gasket - Fits PL75 Series Base Shoe
- Available in 4 Architectural Finishes, - Install With CT040 High Bond
Powder coat options available Tape or S790BL Silicone
- Install With CT040 High Bond - Custom End Caps Available
Tape or S790BL Silicone Contact FHC Technical Sales
- Custom Fabrication Services Available. for a Quote
Contact FHC Technical Sales for a Quote

FHC PRECISION LOCK PLUS ® CLADDING FHC PRECISION LOCK PLUS ® END CAP
ITEM NO. DESCRIPTION FINISH ITEM NO. FINISH
PLC10BS 120' Long Brushed Stainless PLC75ECBS Brushed Stainless
PLC10PS 120' Long Polished Stainless PLC75ECPS Polished Stainless
PLC10SA 120' Long Satin Anodized PLC75ECSA Satin Anodized
PLC10MB 120' Long Matte Black PLC75ECMB Matte Black
Minimum Order: 1 Each. Minimum Order: 1 Each.
visit fhc-usa.com to search for
Precision Lock Plus 4361 Firestone Blvd. South Gate, CA 90280
Toll Free: (888) 295-4531 | Direct: (323) 968-2031
Enter the Item Number or scan QR code with
your smartphone for complete product details Fax: (323) 336-8307 | fhc-usa.com V
